Key Features - HP Visualize J7000 Supplementary Manual

Key Features

The J5000 and J7000 workstations have the following key features.
• CPUs:
— J5000 Two 440 MHz PA-8500 microprocessors, each with 1.5 MB on-chip cache
–
— J7000 Four 440 MHz PA-8500 microprocessors, each with 1.5 MB on-chip cache
–
• Operating System: Native HP-UX
— 32-bit support requires HP-UX version 10.20 plus the June 1999 Workstation ACE
(Additional Core Enhancements)
— 64-bit support requires HP-UX version 11.0 or later
• User Interface: HP CDE (Common Desktop Environment) graphical user interface
• Compatibility: Source- and binary-code compatible with the B
product families
• Main Memory: Using 256 MB or 512 MB DIMMs
— J5000 Eight DIMM slots (from 512 MB up to 4 GB total)
–
— J7000 Sixteen DIMM slots in pairs (from 4 GB up to 8 GB total)
–
• Power Supply:
— J5000 – 830 Watt with no DC/DC converter units
— J7000 – 1,350 Watt with two DC/DC converter units
• Internal Storage Devices:
— Up to four hot-pluggable, SCA (Single Connector Attach) hard disk drives
— Optionally, one 32X CD drive
— Optionally, either one DDS-3 tape drive or one 3.5-inch floppy disk drive
• Standard Networking: Ethernet IEEE 802.3 RJ45, Twisted Pair 10/100 Base T
• Standard I/O: 2 GB/sec aggregate I/O bandwidth
— Two RS-232C Serial ports
— Two USB (Universal Serial Bus) Series A ports for the keyboard and mouse only
— One Parallel (IEEE 1284) port
— One NSE (Narrow Single-Ended) SCSI-2 port
— One Ultra2 Wide LVD (Low Voltage Differential) SCSI port
— Four 16-bit Audio ports (Mic In, Headphones, Line Out, Line In)
Chapter 1
Product Information
Product Description
, C-, and J-Class
-
15
