Express-VR7 User's Guide
COM Port Description
COM 1
Supported by module (SER0, A98/A99), via embedded controller
COM 2
Supported by module (SER1, A101/A102), via embedded controller
COM 3
Supported by Super I/O (W83627DHG) on carrier board
COM 4
Supported by Super I/O (W83627DHG) on carrier board
GPIO or SD
4 GPO and 4 GPI (GPI with interrupt, TBC)
GPI and GPO from CPU GPIO are supported by BOM option and project basis

2.6. Trusted Platform Module (TPM)

Chipset: Infineon solution
Type: TPM 2.0 (SPI bus-based)
TPM chip is supported by project basis

2.7. SEMA Board Controller

Supports: Voltage/current monitoring, power sequence debug support, AT/ATX mode control, logistics and forensic information, flat panel control,
general purpose I2C, failsafe BIOS (dual BIOS, opt. support), watchdog timer and fan control
Page 16
IRQ
4
3
5
7
Copyright © 2024 ADLINK Technology, Inc.
Address
Console Redirection Support
0x3F8
Yes
0x2F8
Yes
0x240
Yes
0x248
Yes
PICMG COM.0 R3.1
