Express-VR7 User's Guide PICMG COM.0 R3.1

2.11. Mechanical and Environmental

Form Factor and specification
PICMG COM Express Rev 3.1 (COM.0 R3.1), Type 7, Basic size 125 x 95 mm
Operating Temperature
Standard 0°C to 60°C Storage: -20°C to 80°C
Extreme Rugged -40°C to 85°C Storage: -40°C to 85°C (build option by project basis, selected SoC SKUs)
Humidity
5-90% RH operating, non-condensing, 5-95% RH storage (and operating with conformal coating)
Shock and Vibration
IEC 60068-2-64 and IEC-60068-2-27
MIL-STD-202F, Method 213B, Table 213-I, Condition A and Method 214A, Table 214-I, Condition D
HALT tested
Thermal Stress, Vibration Stress, Thermal Shock and Combined Test
