Express-VR7 User's Guide
4.3.4

PCI Express

Name Pin # Description
PCIE_TX0+ A68 PCI Express channel 0, Transmit Output differential pair.
PCIE_TX0- A69
PCIE_RX0+ B68 PCI Express channel 0, Receive Input differential pair.
PCIE_RX0- B69
PCIE_TX1+ A64 PCI Express channel 1, Transmit Output differential pair.
PCIE_TX1- A65
PCIE_RX1+ B64 PCI Express channel 1, Receive Input differential pair.
PCIE_RX1- B65
PCIE_TX2+ A61 PCI Express channel 2, Transmit Output differential pair.
PCIE_TX2- A62
PCIE_RX2+ B61 PCI Express channel 2, Receive Input differential pair.
PCIE_RX2- B62
PCIE_TX3+ A58 PCI Express channel 3, Transmit Output differential pair.
PCIE_TX3- A59
PCIE_RX3+ B58 PCI Express channel 3, Receive Input differential pair.
PCIE_RX3- B59
PCIE_TX4+ A55 PCI Express channel 4, Transmit Output differential pair.
PCIE_TX4- A56
PCIE_RX4+ B55 PCI Express channel 4, Receive Input differential pair.
PCIE_RX4- B56
PCIE_TX5+ A52 PCI Express channel 5, Transmit Output differential pair.
PCIE_TX5- A53
PCIE_RX5+ B52 PCI Express channel 5, Receive Input differential pair.
PCIE_RX5- B53
PCIE_TX8+ A71 PCI Express channel 8, Transmit Output differential pair.
PCIE_TX8- A72
PCIE_RX8+ B71 PCI Express channel 8, Receive Input differential pair.
PCIE_RX8- B72
PCIE_TX9+ A74 PCI Express channel 9, Transmit Output differential pair.
PCIE_TX9- A75
Page 29 Copyright © 2024 ADLINK Technology, Inc.
I/O PU / PD Comment
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE AC coupled on Module
I PCIE AC coupled off Module
O PCIE Not supported
I PCIE Not supported
O PCIE Not supported
PICMG COM.0 R3.1
