2.7.

Trusted Platform Module (TPM)

Chipset: Infineon SLB 9665XT2.0
Version: TPM 2.0
2.8.

SEMA Board Controller

Type: ADLINK Smart Embedded Management Agent (SEMA)
Functions:
•
Voltage/Current monitoring
•
Power sequence debug support
•
AT/ATX mode control
•
Logistics and forensic information
•
Flat panel control
•
General purpose I2C
•
Failsafe BIOS (dual BIOS by build option)
•
Watchdog timer and fan control
2.9.

Debug

40-pin flat cable connector to be used with DB-40 debug module
Supports: BIOS POST code LED, BMC access, SPI BIOS flashing, power testpoints, debug LEDs
60-pin XDP header for ICE debug of CPU/chipset

2.10. Power Specifications

Power Modes
Standard Voltage Input
Wide Voltage Input
Power Management
Power States

2.11. Power Consumption

Please contact your ADLINK representative for the document "COM Express Module Power Consumption".
Specifications
AT and ATX mode (AT mode startup controlled by SEMA Board Controller)
ATX: 12V±5% / 5Vsb ±5%; or AT: 12V±5%
ATX: 8.5-20V, 5Vsb ±5%; or AT: 8.5-20V
ACPI 5.0 compliant, Smart Battery support
Supports C1-C6, S0, S3, S4, S5, S5 ECO mode (Wake on USB S3/S4, WOL S3/S4/S5)
Express-KL2
5
