Express-VR7 User's Guide

5. Additional Features

This chapter describes connectors, LEDs, switches and additional items located on the module and not necessarily included in the PICMG standard spec-
ification. The locations of these items are shown below:
Page 52
40-pin Debug
Connector
Figure 3 – Module feature locations
Copyright © 2024 ADLINK Technology, Inc.
Status
Fan
LEDs
12V
PICMG COM.0 R3.1
BIOS Default
Reset Button
BIOS Boot
Select
