- Page 1 EXP-ETH8 EPIC Express Add-on-Board Technical Manual TME-EXP-ETH8-1V3 Revision 1.3 / February 14 ©LiPPERT Adlink Technology GmbH Hans-Thoma-Str. 11 D-68163 Mannheim http://www.adlinktech.com This datasheet has been downloaded from http://www.digchip.com at this page...
- Page 2 Technical Manual EXP-ETH8 LiPPERT Document: TME-EXP-ETH8-1V3 Revision 1.3 Copyright © 2009 LiPPERT Adlink Technology GmbH, All rights reserved Contents and specifications within this manual are subject of change without notice. Trademarks Windows XP is a trademark of Microsoft Corporation. EPIC Express is a registered trademark of PC/104 Consortium.
-
Page 3: Table Of Contents
Features ..................................1 Block Diagram ................................ 2 Ordering Information ........................ 3 EXP-ETH8 Models ..............................3 Specifications ..........................4 Electrical Specifications ............................4 Environmental Specifications ........................... 4 Mean Time Between Failures ........................... 4 ... - Page 4 Bottom PCI/104-Express Connector ......................14 Appendix A, Contact Information Appendix B, Additional Information Appendix C, Getting Help Appendix D, Revision History Acronyms Received Data Transmitted Data Universal Serial Bus TME-EXP-ETH8-1V3 Rev 1.3...
-
Page 5: Overview
The state of link, speed and activity is show by two LEDs on every socket. The EXP-ETH8 supports Stack-up and Stack-down to a CPU Module. Furthermore the EXP-ETH8 uses the 5 Volt and 3.3 Volt power supplied from the PCI/104-Express connector. All other voltages are generated on the board itself. -
Page 6: Block Diagram
Auto MDI, MDI-X crossover at all speeds Receive Side Scaling with two hardware Manageability receive queues SMBus advanced pass through interface 9 KB jumbo frame support 32 KB packet buffer size Block Diagram TME-EXP-ETH8-1V3 Rev 1.3 Page 2 of 17... -
Page 7: Ordering Information
1.2 Ordering Information EXP-ETH8 Models Order number Description 714-0004-10 EXP-ETH8 with eight galvanic isolated 10/100/1000 MBit/s Operating temp. range: 0°C…+60°C 814-0004-10 EXP-ETH8 with eight galvanic isolated 10/100/1000 MBit/s Operating temp. range: -20°C…+60°C 914-0004-10 EXP-ETH8 with eight galvanic isolated 10/100/1000 MBit/s Operating temp. -
Page 8: Specifications
Temperature range -40 … 85 °C Temperature change max. 10K / 30 minutes Humidity (relative) 5 … 95 % (non-condensing) Pressure 450 … 1100 hPa Mean Time Between Failures MTBF at 25°C 673.613 hours TME-EXP-ETH8-1V3 Rev 1.3 Page 4 of 17... -
Page 9: Mechanical
Note: It is strongly recommend using plastic spacers instead of metal spacers to mount the board. With metal spacers, there is a possible danger to create a short circuit with the components located around the mounting holes. This can damage the board! TME-EXP-ETH8-1V3 Rev 1.3 Page 5 of 17... - Page 10 chanical vi Front view Side v view System m stack-up vi iew with Hurr icane-QM57 a and heat spre eader Note e For detailed d mechanical drawings or s step files plea ase contact ou u r support department TME-EXP-ETH TH8-1V3 Rev 1.3 Page 6 of 1 17...
- Page 11 Metrics on Top TME-EXP-ETH8-1V3 Rev 1.3 Page 7 of 17...
-
Page 12: Getting Started
2 Getting Started 2.1 Connector Locations Port 1 Port 2 Port 3 Port 4 Port 5 PC/104 Port 6 Plus Port 7 Port 8 PCIe/104 Express TME-EXP-ETH8-1V3 Rev 1.3 Page 8 of 17... -
Page 13: Bottom
Bottom PCIe/104 PC/104 Express Plus TME-EXP-ETH8-1V3 Rev 1.3 Page 9 of 17... -
Page 14: Hardware Setup
Be sure that your power supply is able to provide enough current to your system. An insufficient power supply leads to an instable system. The EXP-ETH8 need an extra heat sink for standard environment temperatures from –20 °C … +60 °C as well as the extended range of -40 °C ... +85 °C. -
Page 15: Module Description
Activity 1 Gbit/s During transmission the green LED A yellow LED indicates that a starts flashing. established connection uses that data rate. TME-EXP-ETH8-1V3 Rev 1.3 Page 11 of 17... -
Page 16: Pc/104-Plus Bus Connector
TME-EXP-ETH8-1V3 Rev 1.3 Page 12 of 17... - Page 17 TME-EXP-ETH8-1V3 Rev 1.3 Page 13 of 17...
- Page 18 PCI/104 Express Bus Interface The EXP-ETH8 uses x16 link of the PCI/104-Express bus. Which link is used depends if the board is stacked-up or stacked -down. On the module there is a PCI Express switch that detects the type of connection and forwards the other links according to the specification.
- Page 19 Pex1_2 Rn Pex1_3 Rn Pex1_1Clkp Pex1_0Clkp Pex1_1Clkn Pex1_0Clkn +5V_Always +5V_Always Pex1_2Clkp Pex1_3Clkp Pex1_2Clkn Pex1_3Clkn CPU_DIR PWRGOOD SMB_DAT Pex16_Clkp SMB_CLK Pex16_Clkn SMB_ALERT PSON# TME-EXP-ETH8-1V3 Rev 1.3 Page 15 of 17...
- Page 20 Pex16_0T(4)p Pex16_0T(12)n Pex16_0T(4)n Pex16_0T(13)p Pex16_0T(5)p Pex16_0T(13)n Pex16_0T(5)n Pex16_0T(14)p Pex16_0T(6)p Pex16_0T(14)n Pex16_0T(6)n Pex16_0T(15)p Pex16_0T(7)p Pex16_0T(15)n Pex16_0T(7)n Signal Signal SDVO DAT SDVO CLK Pex16_0R(8)p Pex16_0R(0)p Pex16_0R(8)n Pex16_0R(0)n Pex16_0R(9)p Pex16_0R(1)p Pex16_0R(9)n Pex16_0R(1)n Pex16_0R(10)p Pex16_0R(2)p Pex16_0R(10)n Pex16_0R(2)n TME-EXP-ETH8-1V3 Rev 1.3 Page 16 of 17...
- Page 21 Pex16_0R(11)p Pex16_0R(3)p Pex16_0R(11)n Pex16_0R(3)n Pex16_0R(12)p Pex16_0R(4)p Pex16_0R(12)n Pex16_0R(4)n Pex16_0R(13)p Pex16_0R(5)p Pex16_0R(13)n Pex16_0R(5)n Pex16_0R(14)p Pex16_0R(6)p Pex16_0R(14)n Pex16_0R(6)n Pex16_0R(15)p Pex16_0R(7)p Pex16_0R(15)n Pex16_0R(7)n TME-EXP-ETH8-1V3 Rev 1.3 Page 17 of 17...
-
Page 22: Appendix A, Contact Information
Appendix A, Contact Information Headquarters LiPPERT ADLINK Technology GmbH Hans-Thoma-Straße 11 68163 Mannheim Germany Phone +49 621 43214-0 +49 621 4321430 E-mail sales: emea@adlinktech.com Support: helpdesk@adlinktech.com RMA: RMA.EMEA@adlinktech.com Website http://www.adlinktech.com/rugged/index.php TME-EXP-ETH8-1V3 Rev 1.3 Appendix A... -
Page 23: Additional Information
Appendix B, Additional Information B.1 Additional Reading Datasheet of the PEX8618 at http://www.plxtech.com B.2 PCI/104 Express A copy of the latest PCI/104 Express and can be obtained from the PC/104 Consortium's website at www.pc104.org TME-EXP-ETH8-1V3 Rev 1.3 Appendix B... -
Page 24: Getting Help
Please allow one working day for an answer. Returning Products for Repair To return a product to ADLINK Technology GmbH for repair, you need to get a Return Material Authorization (RMA) number first. Please print the RMA Request Form from http://www.adlinktech.com/lippert/rma.php... -
Page 25: Revision History
1.3 MTBF value added 2.3 Software Setup added TME-EXP-ISO-COM8-R1V2.doc 2011-02-22 1.4 mechanical dimensions corrected Appendix A new US address Ch. 1.4 clarified stacking height 22m, mechanical TME-EXP-ISO-COM8-R1V3.doc 2014-02-03 view added Ch. 3.4 SAMTEC part number corrected TME-EXP-ETH8-1V3 Rev 1.3 Appendix D...
