Express-TL User's Guide
On-board Storage
Soldered type PCIe NVMe SSD, available capacities: 60GB/120GB/240GB. Build option support by project basis
Note: For the NVMe SSD build option, DIMM support is limited to 3 slots. Please contact your local ADLINK representative for details.
UART
Two UART interfaces SER0 and SER1 RX/TX on module
Console Redirection via COM 1 or COM 2 selectable in BIOS
Up to 4 serial ports supported by standard BIOS, including Super I/O on carrier board
COM Port Description
COM 1
Supported by module (SER0, A98/A99), via embedded controller
COM 2
Supported by module (SER1, A101/A102), via embedded controller
COM 3
Supported by Super I/O (W83627DHG) on carrier board
COM 4
Supported by Super I/O (W83627DHG) on carrier board
Note: SER0, SER1 from SoC HSUART are BOM option support by project basis
2.7. Trusted Platform Module (TPM)
Chipset: Infineon solution
Type: TPM 2.0 (SPI bus based)
2.8. SEMA Board controller
Supports: Voltage/current monitoring, power sequence debug support, AT/ATX mode control, logistics and forensic information, flat panel control,
general purpose I
2
C, failsafe BIOS (dual BIOS, opt. support), watchdog timer and fan control
Page 15
IRQ
4
3
5
7
Copyright © 2022 ADLINK Technology, Inc.
Address
Console Redirection Support
0x3F8
Yes
0x2F8
Yes
0x240
Yes
0x248
Yes
PICMG COM.0 R3.0
