Express-VR7 User's Guide
4.4.2
PCI Express
Name
Pin #
Description
PCIE_TX6+
D19
PCI Express channel 6, Transmit Output differential pair.
PCIE_TX6-
D20
PCIE_RX6+
C19
PCI Express channel 6, Receive Input differential pair.
PCIE_RX6-
C20
PCIE_TX7+
D22
PCI Express channel 7, Transmit Output differential pair.
PCIE_TX7-
D23
PCIE_RX7+
C22
PCI Express channel 7, Receive Input differential pair.
PCIE_RX7-
C23
Page 44
Copyright © 2024 ADLINK Technology, Inc.
I/O
PU / PD
Comment
O PCIE
Not supported
I PCIE
Not supported
O PCIE
Not supported
I PCIE
Not supported
PICMG COM.0 R3.1
