Express-VR7 User's Guide
4.4.4

PCI Express

Name
Pin #
Description
PCIE_TX16+
D52
PCI Express channel 16, Transmit Output differential pair.
PCIE_TX16-
D53
PCIE_RX16+
C52
PCI Express channel 16, Receive Input differential pair.
PCIE_RX16-
C53
PCIE_TX17+
D55
PCI Express channel 17, Transmit Output differential pair.
PCIE_TX17-
D56
PCIE_RX17+
C55
PCI Express channel 17, Receive Input differential pair.
PCIE_RX17-
C56
PCIE_TX18+
D58
PCI Express channel 18, Transmit Output differential pair.
PCIE_TX18-
D59
PCIE_RX18+
C58
PCI Express channel 18, Receive Input differential pair.
PCIE_RX18-
C59
PCIE_TX19+
D61
PCI Express channel 19, Transmit Output differential pair.
PCIE_TX19-
D62
PCIE_RX19+
C61
PCI Express channel 19, Receive Input differential pair.
PCIE_RX19-
C62
PCIE_TX20+
D65
PCI Express channel 20, Transmit Output differential pair.
PCIE_TX20-
D66
PCIE_RX20+
C65
PCI Express channel 20, Receive Input differential pair.
PCIE_RX20-
C66
PCIE_TX21+
D68
PCI Express channel 21, Transmit Output differential pair.
PCIE_TX21-
D69
PCIE_RX21+
C68
PCI Express channel 21, Receive Input differential pair.
PCIE_RX21-
C69
PCIE_TX22+
D71
PCI Express channel 22, Transmit Output differential pair.
PCIE_TX22-
D72
PCIE_RX22+
C71
PCI Express channel 22, Receive Input differential pair.
PCIE_RX22-
C72
PCIE_TX23+
D74
PCI Express channel 23, Transmit Output differential pair.
PCIE_TX23-
D75
PCIE_RX23+
C74
PCI Express channel 23, Receive Input differential pair.
PCIE_RX23-
C75
Page 47
Copyright © 2024 ADLINK Technology, Inc.
I/O
PU / PD
Comment
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
O PCIE
AC coupled on Module
I PCIE
AC coupled off Module
PICMG COM.0 R3.1
