2.7. Serial I/O on Module
Chipset: Nuvoton NCT5104D
Ports: 2x UARTs Rx/Tx only, the bit rate can support up to 115.2k bps
Console Redirection: selectable in BIOS, supported during BIOS POST
COM Port Description
COM 1 Supported by module (SER0, A98/A99) via NCT5104D
COM 2 Supported by module (SER1, A101/A102) via NCT5104D 5
COM 3 Supported by Super I/O (W83627DHG) on carrier board
COM 4 Supported by Super I/O (W83627DHG) on carrier board
2.8.

Trusted Platform Module (TPM)

Chipset: Infineon
Type: TPM 2.0
2.9.

SEMA Board Controller

Type: ADLINK Smart Embedded Management Agent (SEMA)
Functions:
•
Voltage/Current monitoring
•
Power sequence debug support
•
AT/ATX mode control
•
Logistics and forensic information
•
Flat panel control
•
General purpose I2C
•
Failsafe BIOS (dual BIOS)
•
Watchdog timer and fan control

2.10. Debug

40-pin flat cable connector to be used with DB-40 debug module
Supports: BIOS POST code LED, BMC access, SPI BIOS flashing, power testpoints, debug LEDs
60-pin XDP header for ICE debug of CPU/chipset
Specifications
IRQ Address Console redirection support
7 0x240 Yes
0x248 Yes
4 0x3F8 Yes
3 0x2F8 Yes
