Module Type Definition
Name
Pin #
Description
TYPE0#
C54
The TYPE pins indicate to the Carrier Board the Pin-out Type that is implemented
TYPE1#
C57
on the Module. The pins are tied on the Module to either ground (GND) or are
TYPE2#
D57
no-connects (NC).
For Pin-out Type 1 and Type 10 that lack a CD connector,
these pins are not present (X)
TYPE2#
The Carrier Board should implement combinatorial logic that monitors the
module TYPE pins and keeps power off (e.g deactivates the ATX_ON signal for an
ATX power supply) if an incompatible module pin-out type is detected. The
Carrier Board logic may also implement a fault indicator such as an LED.
TYPE10#
A97
In case of a type 10 module this pin signal is tied to GND through a 47K resistor
on the module.
Page 50
TYPE1#
TYPE0#
X
X
X
X
X
X
NC
NC
NC
NC
NC
GND
NC
GND
NC
NC
GND
GND
GND
NC
NC
GND
NC
GND
Copyright © 2024 ADLINK Technology, Inc.
Pinout Type 1
Pinout Type 10
Pinout Type 2
Pinout Type 3
Pinout Type 4
Pinout Type 5
Pinout Type 6
Pinout Type 7
I/O
PU / PD
Comment
Type 7
No PD
PICMG COM.0 R3.1
