Express-VR7 User's Guide
4.3.9
SMBus
Name
Pin #
Description
SMB_CK
B13
System Management Bus bidirectional clock line. Power
sourced through 3.3V standby rail and main power rails.
SMB_DAT#
B14
System Management Bus bidirectional data line. Power
sourced through 3.3V standby rail and main power rails.
SMB_ALERT#
B15
System Management Bus Alert – active low input can be
used to generate an SMI# (System Management
Interrupt) or to wake the system. Power sourced through
3.3V standby rail and main power rails.
Note: SMBus source from SoC's SMBus is default setting. SMBus source from EC is by build option supported by project basis.
4.3.10 I2C Bus
Name
Pin #
Description
I2C_CK
B33
General purpose I²C port clock output/input
I2C_DAT
B34
General purpose I²C port data I/O line
Note: I2C source from EC is default setting. I2C source from SoC's I2C is by build option supported by project basis.
Page 37
I/O
I/O OD
3.3VSB
I/O OD
3.3VSB
I 3.3VSB
I/O
I/O OD
3.3VSB
I/O OD
3.3VSB
Copyright © 2024 ADLINK Technology, Inc.
PU / PD
Comment
PU 2.2K
Equivalent resistor is 2.2K
3.3VSB
PU 2.2K
Equivalent resistor is 2.2K
3.3VSB
PU 10K
3.3VSB
PU / PD
Comment
PU 2.2K
3.3VSB
PU 2.2K
3.3VSB
PICMG COM.0 R3.1
