Express-VR7 User's Guide
Trigger for Rapid Shutdown. Must be driven to 5V though a <=50-ohm source
RAPID_ C67
impedance for ≥ 20 μs.
SHUTDOWN
USB devices that are to be powered in the S5 / S4 / S3 Suspend states should not
RSMRST_OUT A48
have their 5V VBUS power enabled before RSMRST_OUT# transitions to the hi
state.
Page 41 Copyright © 2024 ADLINK Technology, Inc.
I CMOS Not supported
5VSB
O CMOS
3.3VSB
PICMG COM.0 R3.1
