Express-VR7 User's Guide
4.4.4.1.
I/O Assignments
Please refer to 4.3.4.1
4.4.5

GP_SPI

Name
Pin #
Description
GP_SPI_CS#
D36
Chip select from Module SPI Master to Carrier SPI Slave
GP_SPI_MISO
D34
Data in to Module SPI Master from Carrier SPI Slave
"Master In Slave Out"
GP_SPI_MOSI
D33
Data out from Module SPI Master to Carrier SPI Slave
"Master Out Slave In"
GP_SPI_CLK
D32
Clock from Module SPI Master to Carrier SPI Slave
Note: GP_SPI supported by project basis
Page 49
I/O
O 3.3VSB
I 3.3VSB
O 3.3VSB
O 3.3VSB
Copyright © 2024 ADLINK Technology, Inc.
PU / PD
Comment
PICMG COM.0 R3.1
