2.7.

Serial I/O on Module

Chipset: Nuvoton NCT5104D
Ports: 2x UARTs Rx/Tx only
Console Redirection: COM 1 or COM 2 selectable in BIOS
COM Port Description
COM 1 Supported by module (SER0, A98/A99), via NCT5104D
COM 2 Supported by module (SER1, A101/A102), via NCT5104D
COM 3 Supported by Super I/O (W83627DHG) on carrier board
COM 4 Supported by Super I/O (W83627DHG) on carrier board
2.8.

Trusted Platform Module (TPM)

Chipset: Atmel AT97SC3204
Type: TPM 1.2
2.9.

SEMA Board Controller

Type: ADLINK Smart Embedded Management Agent (SEMA)
Supports:
•
Voltage/Current monitoring
•
Power sequence debug support
•
AT/ATX mode control
•
Logistics and Forensic information
•
Flat Panel Control
•
General Purpose I2C
•
Failsafe BIOS (dual BIOS )
•
Watchdog Timer and Fan Control

2.10. Debug Headers

40-pin multipurpose flat cable connector, used in combination with DB-40 debug module providing BIOS POST code LED, BMC
access, SPI BIOS flashing, power testpoints, debug LEDs
60-pin XDP header for ICE debug of CPU/chipset
IRQ Address Console redirection support
10 0x240
11 0x248
4 0x3F8
3 0x2F8
Express-BL
Yes
Yes
Yes
Yes
