Express-VR7 User's Guide
4.3.3

SATA

Name Pin # Description
SATA0_TX+ A16 Serial ATA channel 0, Transmit Output differential pair.
SATA0_TX- A17
SATA0_RX+ A19 Serial ATA channel 0, Receive Input differential pair.
SATA0_RX- A20
SATA1_TX+ B16 Serial ATA channel 1, Transmit Output differential pair.
SATA1_TX- B17
SATA1_RX+ B19 Serial ATA channel 1, Receive Input differential pair.
SATA1_RX- B20
(S)ATA_ACT# A28 ATA (parallel and serial) or SAS activity indicator, active low.
4.3.3.1. I/O Assignments
Name Physical Lane on CPU
SATA0 Lane 10
SATA1 Lane 11
Page 28
Comment
Copyright © 2024 ADLINK Technology, Inc.
I/O PU / PD Comment
AC coupled on Module
O SATA
AC coupled on Module
I SATA
AC coupled on Module
O SATA
AC coupled on Module
I SATA
O 3.3V PU 10K 3.3V
PICMG COM.0 R3.1
