Hardware Installation and Reference Guide
1.3.3

Ports

Table 1-6
Ports
Port
Management port
USB port
Console port
Connector Type
RJ45
USB
RJ45
Description
The management port is
used to set up the onsite or
remote configuration
environment.
Standards compliance:
IEEE802.3ab
Working mode:
10/100/1000 Mbps with
auto-negotiation and full-
duplex
The USB port is connected
with a USB flash drive for
configuration backup and
firmware upgrade.
USB 2.0
FAT32 file format
The console port is
connected to a console for
onsite configuration.
Standards compliance:
RS-232
Working mode: Duplex
Universal Asynchronous
Receiver/Transmitter
(UART)
Baud rate:
○ Range: 9,600 bit/s to
115,200 bit/s
○
Default value: 9,600
bit/s
7
Overview
Accessory
CAT5 or higher
cable
USB 2.0 flash drive
Console cable
