6. Use a 5/32-inch Allen wrench or 5/32-inch T-handle hex key to install the four

screws that secure the transporter to its mounting bracket (circled in Figure 9-21).

Note:

To reach the bottom two screws, insert the hex key through the

right side of the carriage.

Caution:

Be careful not to drop the screws into the transporter or onto

any of the internal components.

Figure 9-21 Installing the transporter screws.

Installing the Transporter
