6. Select Run Utility.
After a brief delay, the Utility Results screen appears, showing that the
configuration file was uploaded and/or the configuration restored.
Note:
If you used the Upload Backup Configuration option, you must then
run the Restore Library Configuration from Backup Configuration File
utility to restore the library configuration.

Replacing the Compact Flash Card in the LCM

Caution:
Do not install the compact flash card from the LCM you replaced
unless directed to do so by SpectraGuard Support. Installing a
corrupted compact flash card can cause the new LCM to fail.
1. Power off the library as described in Power Off the Library on page 21.
2. Using a #1 Phillips screwdriver, remove the two screws securing the protective
cover plate to the LCM (Figure 8-4).
Figure 8-4 Remove the screws securing the protective cover
to the LCM.
3. Remove the cover and set it aside.
4. Push the eject button to eject the compact flash card from the LCM (Figure 8-5).
Figure 8-5 The compact flash eject button and slot.
Cover plate crews
Compact Flash card
Restoring the Library Configuration
Eject button
71
