Turning the Power On and Off

Before you power on the library, make sure that one or both of the provided power
cords are plugged into AC outlets on the back of the library and that the main power
switch above each AC connector is set to the on position. The main AC connections
provide power to the power supply modules, which are controlled from the front panel
power button.
Note:
If the library does not have 2N redundant power supplies, only the
AC connector and main power switch closest to the power supply
modules are used.
If you need to turn off all power to the library, set the main AC power switches to the
off position and disconnect the power cords.

Power On the Library

Press and hold the front panel power button (Figure 1-6) for two to three seconds until
the button's LED illuminates. Wait while the library completes its power-on sequence,
which takes about five minutes, depending on the library configuration. During the
power-on sequence the library initializes all of its installed components. The library is
ready to begin operation when the login screen displays on the front panel.
Power button
Figure 1-6 Press and hold the front panel power button.

Power Off the Library

To power off the library, press and hold the front panel power button (Figure 1-6) for
approximately six seconds or until the button's LED starts flashing. The power-off
sequence takes approximately one minute while the library allows applications to shut
down gracefully.
Note:
If you intend to leave the library powered down for an extended
length of time, set the main power switches on the back of the
library to the off position.
