Technical data
Languages
CE mark
RCM-tick symbol
Ex approval
EtherNet/IP certification
118
EtherNet/IP
2
3
18
Connection for order code for "Output", option N: EtherNet/IP
1
Service interface (CDI -RJ45) and EtherNet/IP interface of the measuring device with access to the integrated
Web server
2
Computer with Web browser (e.g. Internet Explorer) for accessing the integrated device Web server or with
"FieldCare" operating tool with COM DTM "CDI Communication TCP/IP"
3
Standard Ethernet connecting cable with RJ45 plug
Can be operated in the following languages:
• Via "FieldCare" operating tool: English, German, French, Spanish, Italian, Chinese,
Japanese
• Via Web browser
English, German, French, Spanish, Italian, Dutch, Portuguese, Polish, Russian, Turkish,
Chinese, Japanese, Bahasa (Indonesian), Vietnamese, Czech, Swedish, Korean
16.12 Certificates and approvals
Currently available certificates and approvals can be called up via the product
configurator.
The device meets the legal requirements of the applicable EU Directives. These are listed in
the corresponding EU Declaration of Conformity along with the standards applied.
Endress+Hauser confirms successful testing of the device by affixing to it the CE mark.
The measuring system meets the EMC requirements of the "Australian Communications
and Media Authority (ACMA)".
The devices are certified for use in hazardous areas and the relevant safety instructions are
provided in the separate "Safety Instructions" (XA) document. Reference is made to this
document on the nameplate.
The measuring device is certified and registered by the ODVA (Open Device Vendor
Association). The measuring system meets all the requirements of the following
specifications:
• Certified in accordance with the ODVA Conformance Test
• EtherNet/IP Performance Test
• EtherNet/IP PlugFest compliance
• The device can also be operated with certified devices of other manufacturers
(interoperability)
Proline Cubemass C 100 Ethernet/IP
1
Endress+Hauser
A0016940
