Proline Cubemass C 100 Ethernet/IP
Input signal
Output signal
Signal on alarm
Endress+Hauser
External measured values
To increase the accuracy of certain measured variables or to calculate the corrected volume
flow for gases, the automation system can continuously write different measured values to
the measuring device:
• Operating pressure to increase accuracy (Endress+Hauser recommends the use of a
pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar S)
• Medium temperature to increase accuracy (e.g. iTEMP)
• Reference density for calculating the corrected volume flow for gases
Various pressure transmitters and temperature measuring devices can be ordered
from Endress+Hauser: see "Accessories" section →  100
It is recommended to read in external measured values to calculate the following measured
variables:
• Mass flow
• Corrected volume flow
Digital communication
The measured values are written from the automation system to the measuring device via
EtherNet/IP.
16.4

Output

EtherNet/IP
Standards
Depending on the interface, failure information is displayed as follows:
EtherNet/IP
Device diagnostics
Local display
Plain text display
Backlight
Status signal as per NAMUR recommendation NE 107
Interface/protocol
• Via digital communication:
EtherNet/IP
• Via service interface
CDI-RJ45 service interface
Plain text display
In accordance with IEEE 802.3
Device condition can be read out in Input Assembly
With information on cause and remedial measures
Red backlighting indicates a device error.
With information on cause and remedial measures
Technical data
103
