Diagnostics and troubleshooting
88
Diagnostic Short text
number
390 Special event 2
391 Special event 6
392 Special event 10
Diagnostic of configuration
410 Data transfer
411 Up-/download active
437 Configuration
incompatible
438 Dataset
453 Flow override
484 Simulation failure mode
485 Simulation measured
variable
495 Simulation diagnostic
event
537 Configuration
590 Special event 3
591 Special event 7
592 Special event 11
Diagnostic of process
825 Operating temperature
825 Operating temperature
830 Sensor temperature too
high
831 Sensor temperature too
low
832 Electronic temperature
too high
833 Electronic temperature
too low
834 Process temperature too
high
835 Process temperature too
low
842 Process limit
843 Process limit
862 Partly filled pipe
882 Input signal
Proline Cubemass C 100 Ethernet/IP
Remedy instructions
Contact service
Contact service
Contact service
1. Check connection
2. Retry data transfer
Up-/download active, please wait
1. Restart device
2. Contact service
1. Check data set file
2. Check device configuration
3. Up- and download new
configuration
Deactivate flow override
Deactivate simulation
Deactivate simulation
Deactivate simulation
1. Check IP addresses in network
2. Change IP address
Contact service
Contact service
Contact service
1. Check ambient temperature
2. Check process temperature
Reduce ambient temp. around the
sensor housing
Increase ambient temp. around
the sensor housing
Reduce ambient temperature
Increase ambient temperature
Reduce process temperature
Increase process temperature
Low flow cut off active!
1. Check low flow cut off
configuration
Check process conditions
1. Check for gas in process
2. Adjust detection limits
1. Check input configuration
2. Check external device or
process conditions
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
F Alarm
1)
F Alarm
F Alarm
C Warning
F Alarm
M Warning
C Warning
C Alarm
C Warning
C Warning
F Warning
F Alarm
F Alarm
1)
F Alarm
S Warning
F Alarm
S Warning
S Warning
1)
S Warning
1)
S Warning
1)
S Warning
1)
S Warning
S Warning
S Warning
S Warning
F Alarm
