Technical data
Low flow cut off
Galvanic isolation
Protocol-specific data
104
Web browser
Plain text display With information on cause and remedial measures
Light emitting diodes (LED)
Status information
The switch points for low flow cut off are user-selectable.
The following connections are galvanically isolated from each other:
• Outputs
• Power supply
Protocol-specific data
Protocol
Communication type
Device profile
Manufacturer ID
Device type ID
Baud rates
Polarity
Supported CIP connections
Explicit connections
I/O connections
Configuration options for
measuring device
Configuration of the EtherNet
interface
Configuration of the device
address
Device Level Ring (DLR)
Status indicated by various light emitting diodes
The following information is displayed depending on the device version:
• Supply voltage active
• Data transmission active
• Device alarm/error has occurred
• EtherNet/IP network available
• EtherNet/IP connection established

Diagnostic information via light emitting diodes →  79
• The CIP Networks Library Volume 1: Common Industrial Protocol
• The CIP Networks Library Volume 2: EtherNet/IP Adaptation of CIP
• 10Base-T
• 100Base-TX
Generic device (product type: 0x2B)
0x49E
0x104A
Automatic ¹⁰⁄₁₀₀ Mbit with half-duplex and full-duplex detection
Auto-polarity for automatic correction of crossed TxD and RxD pairs
Max. 3 connections
Max. 6 connections
Max. 6 connections (scanner)
• DIP switches on the electronics module for IP addressing
• Manufacturer-specific software (FieldCare)
• Add-on Profile Level 3 for Rockwell Automation control systems
• Web browser
• Electronic Data Sheet (EDS) integrated in the measuring device
• Speed: 10 MBit, 100 MBit, auto (factory setting)
• Duplex: half-duplex, full-duplex, auto (factory setting)
• DIP switches on the electronics module for IP addressing (last octet)
• DHCP
• Manufacturer-specific software (FieldCare)
• Add-on Profile Level 3 for Rockwell Automation control systems
• Web browser
• EtherNet/IP tools, e.g. RSLinx (Rockwell Automation)
No
Proline Cubemass C 100 Ethernet/IP
