Commissioning

54
10 Commissioning
10.1

Function check

Before commissioning the measuring device:
‣
Make sure that the post-installation and post-connection checks have been performed.
• "Post-installation check" checklist→  26
• "Post-connection check" checklist→  33
10.2

Configuring the device address via software

In the "Communication" submenu the device address can be set.
Navigation
"Setup" menu → Communication → Device address
10.2.1

Ethernet network and Web server

When delivered, the measuring device has the following factory settings:
IP address 192.168.1.212
Subnet mask 255.255.255.0
Default gateway 192.168.1.212
• If hardware addressing is active, software addressing is disabled.
• If a switch is made to hardware addressing, the address configured via software
addressing is retained for the first 9 places (the first three octets).
• If the IP address of the device is not known, the device address currently configured
can be read out →  71.
10.3

Setting the operating language

Factory setting: English or ordered local language
The operating language can be set in FieldCare, DeviceCare or via the Web server:
Operation → Display language
10.4

Configuring the measuring device

The Setup menu with its submenus contains all the parameters needed for standard
operation.

Setup
Device tag
‣
System units
‣
Medium selection
Proline Cubemass C 100 Ethernet/IP
→  55
→  55
→  58
