Proline Cubemass C 100 Ethernet/IP
Endress+Hauser
Designation Description (format)
8. Not used
9. Not used
10. Control totalizer 1 (integer)
11. Not used
12. Control totalizer 2 (integer)
13. Not used
14. Control totalizer 3 (integer)
15. Not used
16. External pressure (real)
17. External pressure unit (integer)
18. Not used
19. External reference density (real)
20. External reference density unit
(integer)
21. Not used
22. External temperature (real)
23. External temperature unit
(integer)
24. Not used
25. Start verification (integer)
26. Not used
System integration
Byte Bit
8 –
2-4 0-8 –
5-6 0-8 • -32226: Add
• -32490: Reset and stop
• -32228: Default value and
stop
• 198: Reset and add
• 199: Default value and add
7-8 0-8 –
9-10 0-8 See totalizer 1
11-12 0-8 –
13-14 0-8 See totalizer 1
15-16 0-8 –
17-20 0-8 Data format:
Byte 1 to 4: External pressure
Floating-point number
(IEEE754)
21-22 0-8 • 2165: Pa a
• 2116: kPa a
• 2137: MPa a
• 4871: bar a
• 2166: Pa g
• 2117: kPa a
• 2138: MPa a
• 2053: bar g
• 2182: Psi a
• 2183: Psi g
• 2244: Customer-specific
23-24 0-8 –
25-28 0-8 Data format:
Byte 1 to 4: External ref. density
Floating-point number
(IEEE754)
29-30 0-8 • 2112: kg/Nm
• 2113: kg/Nl
• 2092: g/Scm
• 2114: kg/Scm
• 2181: lb/Sft
31-32 0-8 –
33-36 0-8 Data format:
Byte 1 to 4: External
temperature
Floating-point number
(IEEE754)
37-38 0-8 • 4608: °C
• 4609: °F
• 4610: K
• 4611: °R
39-40 0-8 –
41-42 0-8 • 32378: Start
• 32713: Cancel
43-64 0-8 –
Value
3
3
3
3
53
