Proline Cubemass C 100 Ethernet/IP
Endress+Hauser
Configuration 4: Input Only Multicast
Input Assembly Configurable
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Configuration 5: Exclusive Owner Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Configuration 6: Input Only Multicast
Input Assembly Fix
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Configuration 7: Exclusive Owner Multicast
Input Assembly Configurable
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Configuration 8: Input Only Multicast
Input Assembly Configurable
Input Assembly Configurable
Output Assembly Fix
Input Assembly Fix
Permanently assigned input group
Input Assembly Fix (Assem100) 44 Byte
Designation
Input Assembly Fix
Instance
Configuration 0 x 68
O → T Configuration 0 x C7
T → O Configuration 0 x 64
Instance
Configuration 0 x 69
O → T Configuration 0 x 66
T → O Configuration 0 x 64
Instance
Configuration 0 x 69
O → T Configuration 0 x C7
T → O Configuration 0 x 65
Instance
Configuration 0 x 69
O → T Configuration 0 x 66
T → O Configuration 0 x 64
Instance
Configuration 0 x 69
O → T Configuration 0 x C7
T → O Configuration 0 x 65
Description
1. File header (not visible)
1)
2. Current diagnosis
3. Mass flow
4. Volume flow
5. Corrected volume flow
6. Temperature
7. Density
8. Reference density
9. Totalizer 1
System integration
Size [byte] Min. RPI (ms)
398 –
– –
88 5
Size [byte] Min. RPI (ms)
– –
64 5
44 5
Size [byte] Min. RPI (ms)
– –
– –
44 5
Size [byte] Min. RPI (ms)
– –
64 5
88 5
Size [byte] Min. RPI (ms)
– –
– –
88 5
Byte
1-4
5-8
9-12
13-16
17-20
21-24
25-28
29-32
33-36
