Proline Cubemass C 100 Ethernet/IP
Power consumption
Current consumption
Power supply failure
Electrical connection
Potential equalization
Terminals
Cable entries
Cable specification
Reference operating
conditions
Maximum measured error
Endress+Hauser
Transmitter
Order code for "Output"
Option N: EtherNet/IP
Transmitter
Order code for "Output"
Option N: EtherNet/IP
• Totalizers stop at the last value measured.
• Depending on the device version, the configuration is retained in the device memoryor in
the pluggable data memory (HistoROM DAT).
• Error messages (incl. total operated hours) are stored.
→  29
→  31
Transmitter
Spring terminals for wire cross-sections0.5 to 2.5 mm
• Cable gland: M20 × 1.5 with cable Ø 6 to 12 mm (0.24 to 0.47 in)
• Thread for cable entry:
• M20
• G ½"
• NPT ½"
→  27
16.6

Performance characteristics

• Error limits based on ISO 11631
• Water with +15 to +45 °C (+59 to +113 °F) at2 to 6 bar (29 to 87 psi)
• Specifications as per calibration protocol
• Accuracy based on accredited calibration rigs that are traced to ISO 17025.
To obtain measured errors, use the Applicator sizing tool →  100
o.r. = of reading; 1 g/cm³ = 1 kg/l; T = medium temperature
Base accuracy
Design fundamentals →  110
Mass flow and volume flow (liquids)
±0.10 % o.r.
Maximum
Power consumption
Maximum
Current consumption switch-on current
145 mA 18 A (< 0.125 ms)
2 (20 to 14 AWG)
Technical data
3.5 W
Maximum
107
