Proline Cubemass C 100 Ethernet/IP
Endress+Hauser
Diagnostic Short text
number
910 Tubes not oscillating
912 Medium inhomogeneous
912 Inhomogeneous
913 Medium unsuitable
944 Monitoring failed
948 Tube damping too high
990 Special event 4
991 Special event 8
992 Special event 12
1) Diagnostic behavior can be changed.
12.9

Pending diagnostic events

The Diagnostics menu allows the user to view the current diagnostic event and the
previous diagnostic event separately.
To call up the measures to rectify a diagnostic event:
• Via Web browser →  84
• Via "FieldCare" operating tool →  85
Other pending diagnostic events can be displayed in the Diagnostic list submenu
→  90
Navigation
"Diagnostics" menu
Structure of the submenu
Diagnostics
Diagnostics and troubleshooting
Remedy instructions
1. Check electronic
2. Inspect sensor
1. Check process cond.
2. Increase system pressure
1. Check process conditions
2. Check electronic modules or
sensor
Check process conditions for
Heartbeat Monitoring
Check process conditions
Contact service
Contact service
Contact service
→ Actual diagnostics
Previous diagnostics
Status Diagnostic
signal behavior
[from the [from the
factory] factory]
F Alarm
S Warning
S Warning
S Alarm
S Warning
S Warning
F Alarm
F Alarm
1)
F Alarm
89
