2. On the right in the working area, mouse over the parameter.
 A tool tip with remedy information for the diagnostic event appears.
12.6 Diagnostic information via communication interface
12.6.1

Reading out diagnostic information

The current diagnostic event and associated diagnostic information can be read out via the
input assembly (fix assembly):
Bytes 0
Contents "Empty" or "Reserved"
For content of bytes 8 to 16
12.7

Adapting the diagnostic information

12.7.1

Adapting the diagnostic behavior

Each item of diagnostic information is assigned a specific diagnostic behavior at the
factory. The user can change this assignment for certain diagnostic information in the
Diagnostic behavior submenu .
Expert → System → Diagnostic handling → Diagnostic behavior
You can assign the following options to the diagnostic number as the diagnostic behavior:
Options Description
Alarm Measurement is interrupted. The totalizers assume the defined alarm condition. A
diagnostic message is generated.
Warning Measurement is resumed. The totalizers are not affected. A diagnostics message is
generated.
Logbook entry only The device continues to measure. The diagnostic message is entered in the Event
logbook (events list) submenu only and is not displayed in alternation with the measured
value display.
Off The diagnostic event is ignored, and no diagnostic message is generated or entered.
12.8

Overview of diagnostic information

In the case of some items of diagnostic information, the status signal and the
diagnostic behavior can be changed. Adapt the diagnostic information →  86
1 2 3
↓
"Empty" or "Padding
Proline Cubemass C 100 Ethernet/IP
4 5 6
↓ ↓
Diagnostic number
of diagnostic event
which is displayed
in the Actual
bytes" diagnostics
parameter
→  89, e.g.
242
