Proline Cubemass C 100 Ethernet/IP
Endress+Hauser
The measuring device works with the Dynamic Host Configuration Protocol (DHCP), on
leaving the factory, i.e. the IP address of the measuring device is automatically assigned by
the automation system (DHCP server).
To establish a network connection via the service interface (CDI-RJ45): set the "Default IP
address" DIP switch to ON. The measuring device then has the fixed IP address:
192.168.1.212. This address can now be used to establish the network connection.
1. Via DIP switch 2, activate the default IP address 192.168.1.212: .
2. Switch on the measuring device.
3. Connect to the computer using a cable →  117.
4. If a 2nd network card is not used, close all the applications on the notebook.
 Applications requiring Internet or a network, such as e-mail, SAP applications,
Internet or Windows Explorer.
5. Close any open Internet browsers.
6. Configure the properties of the Internet protocol (TCP/IP) as defined in the table:
IP address
Subnet mask
Default gateway
Starting the Web browser
1. Start the Web browser on the computer.
192.168.1.XXX; for XXX all numerical sequences except: 0, 212 and 255 → e.g.
192.168.1.213
255.255.255.0
192.168.1.212 or leave cells empty
Operation options
