Proline Cubemass C 100 Ethernet/IP
Parameter
Device tag
Endress+Hauser
Communication
Low flow cut off
Partially filled pipe detection
Advanced setup
10.4.1

Defining the tag name

To enable fast identification of the measuring point within the system, you can enter a
unique designation using the Device tag parameter and thus change the factory setting.
Enter the tag name in the "FieldCare" operating tool →  48
Navigation
"Setup" menu → Device tag
Parameter overview with brief description
Description
Enter the name for the measuring point.
10.4.2

Setting the system units

In the System units submenu the units of all the measured values can be set.
The number of submenus and parameters can vary depending on the device version.
Certain submenus and parameters in these submenus are not described in the
Operation Instructions. Instead a description is provided in the Special Documentation
for the device (→ "Supplementary documentation" section).
Navigation
"Setup" menu → Advanced setup → System units
System units
Mass flow unit
Mass unit
Volume flow unit
Volume unit
Corrected volume flow unit
Corrected volume unit
User entry
Max. 32 characters, such as
letters, numbers or special
characters (e.g. @, %, /).
Commissioning
→  59
→  62
→  63
→  64
Factory setting
Promass 100
→  56
→  56
→  56
→  56
→  56
→  56
55
