System integration
52
Designation
1) Structure: Code, number, description (e.g.: 16777265 F882 input signal)
Detailed description:
• Diagnostic information
• Information events →  91
Configurable input group
Input Assembly Configurable (Assem101) 88 byte
Designation
Input Assembly Configurable
Possible input values
Possible input values 1 to 10:
• Off
• Mass flow
• Volume flow
• Corrected volume flow
1)
• Target mass flow
1)
• Carrier mass flow
• Density
• Reference density
1)
• Concentration
1) Only available with the Concentration application package
2) Only available with the Heartbeat Verification application package
Possible input values 11 to 20:
• Off
• Current diagnosis
• Previous diagnosis
• Mass flow unit
• Volume flow unit
• Corrected volume flow unit
Permanently assigned output group
Output Assembly Fix (Assem102) 64 byte
Designation Description (format)
Output 1. Totalizer 1
Assembly Fix
2. Totalizer 2
3. Totalizer 3
4. Pressure compensation
5. Reference density compensation
6. Temperature compensation
7. Verification
Description
10. Totalizer 2
11. Totalizer 3
(Verweisziel existiert nicht, aber @y.link.required=' t rue' )
Description
1. - 10. Input values 1 to 10
11. - 20. Input values 11 to 20
• Temperature
• Carrier tube temperature
• Electronic temperature
• Oscillation frequency 0
• Oscillation amplitude 0
• Oscillation frequency 0
• Oscillation damping 0
• Signal shift
• Temperature unit
• Density unit
• Reference density unit
• Concentration unit
• Current unit
• Verification status
Byte
1
Proline Cubemass C 100 Ethernet/IP
Byte
37-40
41-44
Format
Real
Double integer
• Tube damping fluctuation 0
2)
• Exciter current 0
• Monitoring of exciter current 0
• Totalizer 1
• Totalizer 2
• Totalizer 3
• Totalizer 1 unit
• Totalizer 2 unit
• Totalizer 3 unit
• Verification result
Bit Value
1
2
3
• 0: Disable
4
• 1: Enable
5
6
7
