Electrical connection
30
7.3.1
Connecting the transmitter
The connection of the transmitter depends on the following order codes:
• Housing version: compact or ultra-compact
• Connection version: device plug or terminals
A
1
8
Housing versions and connection versions
A
Housing version: compact, coated, aluminum
B
Housing version: compact, hygienic, stainless
1
Cable entry or device plug for signal transmission
2
Cable entry or device plug for supply voltage
C
Housing version: ultra-compact, hygienic, stainless
3
Device plug for signal transmission
4
Device plug for supply voltage
3 mm
2
1
mm (in)
9
Device versions with connection examples
1
Cable
2
Device plug for signal transmission
3
Device plug for supply voltage
Proline Cubemass C 100 Ethernet/IP
B
2
1
2
8 mm
2
1
1
2
10 (0.4)
C
3
4
8 mm
2
3
3
Endress+Hauser
A0016924
A0017844
