Indicator
Water level
Charge current
and voltage

Alternate Battery Display

You can switch the battery graphical display to an alternate tabular battery display
showing additional parameters for the charging battery.
Part Number 5911110 A02
Description
Drop/Background
Color
Blue drop and white
background
Blue drop and red
background
Grey drop and white
background
NOTE
There is no drop if there is a CAN battery or if there is
no BMID (voltage mode).
The charger controls the charging current via Webasto
proprietary charging algorithms.
Page 52 of 112
Indication
OK – the battery water
level is OK.
LOW – the battery water
level is low.
There is a BMID with a
no water level sensor
