A3. Error Codes produced by base system.
Error Codes
E61
E62
E63
E64
E65
E66
E67
E68
E70
E71
E72
E73
E74
E75
E76
E77
E78
E79
E80
E81
E82
E83
E84
E85
E86
E87
E88
E89
E90
E91
E92
E93
E94
E95
E96
E97
E98
For diagnosis, contact The Magstim Company Limited service department (see Section 7.2 for contact
details).
© The Magstim Company Limited
Description
Power fail
Stack underflow
Stack overflow
RTS overrun
WD Timeout
Unexpected reset
Bad checksum
SYS debug error
Coil under temperature
Coil max difference
Stack over temperature
Stack under temperature
Stack max difference
HVCAP over temperature
HV Transformer over temperature
Charge threshold failure
VREF check failure
HVCAP voltage comparison failure
Charging fault
HV over voltage
Invalid system configuration
Stop line fault
Base coil stop line fault
UI stop line fault
Dump system fault
Invalid coil category for current system configuration.
Invalid NVRAM Checksum.
Faulty charging relay detected
Base arm LED drive failure
External PSU Fault
Base over temperature
Snubber board over temperature
Base under temperature
HV CAP under temperature
Snubber board under temperature
Ambient over temperature
System failed to produce protocol
56
Magstim Rapid²
Operating Manual
MOP03-EN-03
