3.2.1.10
This Mainframe contains the circuitry that allows the stimulator to deliver energy as specified using the
UI.
3.2.1.11
This module is a combination of PSU and control circuitry that allows additional performance
compared to that of a Standard or Super Rapid
3.2.1.12
The dual PSU contains the electronic circuitry that powers the stimulator.
Rear view
3.2.2
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
Note: 115V units are identical in appearance to the 230V units, with the exception of the
voltage/power rating labels sited to the rear
© The Magstim Company Limited
Main Frame (10)
1
Plus Module (11)
Dual Power Supply Unit (PSU) (12)
Figure 3.8: Detailed rear panel of Rapid² Plus¹.
2
system.
12
Magstim Rapid²
Operating Manual
(9)
(10)
(11)
(12)
(13)
(14)
(15)
