  • Page 1 Magstim BiStim² Operating Manual MOP02-EN Revision 02 January 2014...

  • Page 2: Table Of Contents

    Product Enquiries ....................22 Servicing Enquiries ....................22 Sales Enquiries ..................... 22 Appendix A – SYSTEM ERROR CODES ................23 Appendix B – Trigger Input / Output ..................25 Appendix C – MANUFACTURER’S EMC DECLARATIONS ..........26 © The Magstim Company Limited MOP02-EN-02...

  • Page 3: Guarantee

    Equipment manufactured by The Magstim Company Limited is fully guaranteed, covering both materials and workmanship, for a period of one year from the date of shipment. The Magstim Company Limited reserves the right to perform guarantee services in its factory, at an authorised repair station, or at the customer’s installation.

  • Page 4: Introduction

    The Magstim Bistim² consists of two Magstim 200² units and a Magstim Bistim² Connecting Module. This enables the outputs of the two Magstim 200² units to output into a single stimulating coil either as a single high energy pulse or as a pair of individual spaced pulses.

  • Page 5: Devices Covered

     Magstim 200² UI Controller (P/N: 3020-00) All parts of the Magstim BiStim² system, referenced above are suitable for use within the patient environment. Note: When the Bistim² Connecting Module is not connected, the Magstim 200² Units will operate as if they were a standalone device.

  • Page 6: Warnings And Precautions

    Damage: If there are any signs of damage to the Magstim BiStim² System, or if any parts are damp or wet, the system must not be used. If damaged, the Magstim BiStim² should be returned to the Magstim Company Limited for servicing and repair (see Section 7.2 for contact details).
  • Page 7 6.3 of this operating manual. Stacking Limit: Magstim 200² units may be stacked on top of each other, but must not exceed the stacking limit specified in Section 6 of this operating manual. If this limit is exceeded, the stack may become unstable and overbalance risking injury to patients or users and risking damage to the unit’s themselves.

  • Page 8: Product Descriptions

    3.1.1 On/Off Button* (1) The on/off button toggles the master and slave units of the Magstim Bistim² between on and standby. 3.1.2 Armed Indicator* (2) & (9) The armed indicator illuminates when the unit is armed allowing it to be triggered.
  • Page 9 The surface temperature of the connected coil has risen above its set limit. The connected coil is faulty. There is no coil connected. If this LED is illuminated the Magstim Bistim² will not arm until the reason for the indicator being lit is resolved. © The Magstim Company Limited...
  • Page 10 Run Button* (11) The Magstim Bistim² can be armed pushing the green run button. The Magstim Bistim² will charge to the power level indicated on the output display. The Magstim Bistim² will not arm if the replace coil indicator is illuminated.
  • Page 11 Note: It is normal for the pin indicated on the label to protrude from the coil socket on the master and slave stimulator units. This is an intentional design feature. Figure 3.2: Coil output socket front view Figure 3.3: Coil output socket angled view © The Magstim Company Limited MOP02-EN-02...

  • Page 12: Rear Panel

    The Power switch allows the power supplying the unit to be switched on (labelled I) or off (labelled 3.2.2 Isolated Interface* (2) The trigger input is used to synchronise the Magstim Bistim² system to an external trigger input. This is only functional on the master unit. Please see Appendix B for more information. 3.2.3 Foot Switch Socket* (3) This socket is used to connect the pneumatic foot switch to the Magstim Bistim²...

  • Page 13: Accessories

    3.2.4 Cooling Fan Outlet (4) With the Magstim Bistim² turned on, air is drawn through slots at the bottom of the instrument and expelled through the fan outlet. There should be no obstructions placed closer than 50mm to the fan outlet.

  • Page 14: Operating Instructions

    Note: ensure not to position the Magstim BiStim², so it is difficult to disconnect the power lead. 1. Ensure that the master and slave units of the Magstim Bistim² are switched off on the rear 2. Place the master unit on top of the slave unit ensuring the feet of the master unit fit into the recesses on the slave unit 3.
  • Page 15 Phillips screw driver. Place one end of the earth strap over the screw as shown in figure 4.3 and re-attach to the unit back panel. 11. Figure 4.3: Attaching the earth strap Repeat the above, to attach the opposite end of the earth strap to the slave unit. © The Magstim Company Limited MOP02-EN-02...

  • Page 16: Connection

    1. If a foot switch is to be used, insert the pneumatic connector of the foot switch to the rear panel Foot Switch Socket on the master unit of the Magstim Bistim² system 2. If an external triggering or recording device is to be used, connect it to the Isolated Interface on the rear of the master unit of the Magstim Bistim²...

  • Page 17: Operation

    Note: During the initialisation sequence, the operator must check that all LED’s are lit. If they do not, the items must not be used and should be returned to The Magstim Company Limited for servicing and repair.

  • Page 18: Independent Bistim² Triggering (Ibt)

    UI or the foot switch*. A clicking noise should be heard from both the stimulating coil and the Magstim Bistim² system. If the inter-pulse spacing is large enough, two clicks should be audible.

  • Page 19: Maintenance

    . If any cracks are visible in the plastics, or if there is damage to any of the cables, the items must not be used and should be returned to The Magstim Company Limited for servicing and repair (see Section 7.2 for contact details).

  • Page 20: Voltage Selection And Fuse Rating

    Magstim Company Limited (see Section 7.2 for contact details). Device Lifetime The lifetime of the Magstim Bistim² system is defined as being five years from the date of shipment. The Magstim Company Limited will support the products for the duration of their lifetime.

  • Page 21: Disposal

    Operating Manual Disposal When a Magstim Bistim² system or accessory reaches the end of its serviceable life, it should not be disposed of in general waste. The Magstim Company Limited should be contacted (see Section 7.2 for contact details) for advice on its disposal in compliance with the appropriate environmental regulations.

  • Page 22: Specifications

    SECTION 6 SPECIFICATIONS Safety Specifications During use, the type of protection against electric shock provided by the Magstim Bistim² system is classified as Class 1. The degree of protection against electric shock for applied part accessories is classified as Type BF Applied Parts.

  • Page 23: Technical Specifications

    Bistim² Connecting Module: Dimensions: 135mmx x 81mm x 165mm Weight: 1.62kg Software: Version 1.9 Controller Board Software: (Software ref: 3056) Version 1.1 UI Controller Software: (Software ref: 3026) Please note: All specifications are subject to alteration. © The Magstim Company Limited MOP02-EN-02...

  • Page 24: Environmental Conditions

    Figure 6.1: Guidelines on lifting and lowering Packing Instructions If, for any reason, it is necessary to return your Magstim Bistim² care should be taken to ensure that the equipment is adequately packed to prevent transit damage. Ideally the equipment should be returned in its original packing.

  • Page 25: Contact Details

    +44 (0)1994 240798 Fax: +44 (0)1994 240061 E-mail: info@magstim.com Website: www.magstim.com Servicing Enquiries Telephone: +44 (0)1994 242900 Fax: +44 (0)1994 240061 E-mail: service@magstim.com Sales Enquiries Telephone: +44 (0)1994 241111 Fax: +44 (0)1994 242917 E-mail: sales@magstim.com © The Magstim Company Limited MOP02-EN-02...

  • Page 26: Appendix A - System Error Codes

    Bad Serial command of received data checksum (outside TRIGGATE). EMC Detected (Coil adapter only). Invalid Coil Power Identification (Coil adapter only). Hardware Stop activated. Watchdog Timeout. Temperature Interlock 3 activation. Coil stop line fault. © The Magstim Company Limited MOP02-EN-02...
  • Page 27 Invalid coil category for current system configuration. Invalid NVRAM Checksum. Faulty charging relay detected Base arm LED drive failure For diagnosis, contact The Magstim Company Limited service department (see Section 7.2 for contact details). © The Magstim Company Limited MOP02-EN-02...

  • Page 28: Appendix B - Trigger Input / Output

    Trigger Edge / Level When set to edge trigger, the Magstim Bistim² will only be triggered when the logic level being applied on the Tin+ or Tin- pin is changed. On the Tin+ pin, triggering will occur when the logic level is changed from low to high. On the Tin- pin, triggering will occur when the logic level is changed from high to low.

  • Page 29: Appendix C - Manufacturer's Emc Declarations

    APPENDIX C – MANUFACTURER’S EMC DECLARATIONS Guidance and Manufacturer’s Declaration – Electromagnetic Emissions The Magstim Bistim² is intended for use in the electromagnetic environment specified below. The customer or the user of the equipment should assure that it is used in such an environment.
  • Page 30 Operating Manual Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The Magstim Bistim² is intended for use in the electromagnetic environment specified below. The customer or the user of the equipment should assure that it is used in such an environment.
  • Page 31 Operating Manual Guidance and Manufacturer’s Declaration – Electromagnetic Immunity The Magstim Bistim² is intended for use in the electromagnetic environment specified below. The customer or the user of the equipment should assure that it is used in such an environment.
