Date: Use 'Modify' to alter the 'Date Settings'
Time: Use 'Modify' to alter the 'Date Settings'
Modify: To change the date and the time settings, select the Modify button. Individual windows
appear to allow date, month, year, hour, minute and second to be altered. Press to select a window
and alter the information using the Rotary Control Knob. To save press the Set Time button.
Language Setup: This option allows the user to change the language of the displays. German,
English and French are available. English is the Default language.
Battery Voltage: This window displays the UI's backup battery voltage.
Back: Selection of this option takes you back to Systems Options Menu.
Options Menu: Selection of this option will return the user to the Options Menu Screen.
4.4.5.2
This screen shows the part numbers, revision
and serial number information for UI, MEP
Pod, Main Frame, PSU, Plus
applicable) and attached coil.
Print: For Print Operations See Section 4.4.8.
Back: Returns the user to the System Options
Menu.
4.4.5.3
This screen is intended for Service Personnel.
Clear: This button clears the password
window.
Enter: This button enters the current number in
the password window for verification. If correct,
the service menus are displayed.
Back: This option returns the user to the
System Options Menu screen.
© The Magstim Company Limited
System Details
1
System Configuration
module (if
Figure 4.26: System Details Window
Figure 4.27: System Configuration Window
38
Magstim Rapid²
Operating Manual
MOP03-EN-03
