3.2.2.1
The UI cable connects the Rapid² UI to the Rapid² mainframe.
3.2.2.2
The Power switch allows the power supplying the unit to be switched on (labelled I) or off (labelled O).
3.2.2.3
Access for fuse replacement and changing the voltage selector setting. See section 5.3 for further
details.
3.2.2.4
Power input port on the Rapid² mainframe and Plus¹ module.
3.2.2.5
The 10A link lead provides powers to the Plus¹ from the PSU and to the mainframe from the Plus¹.
3.2.2.6
The Power switch allows the power supplying the Plus¹ module unit to be switched on (labelled I) or
off (labelled O).
3.2.2.7
This connector is the HV output on the Plus¹ which interconnects the high voltage power between the
mainframe and the Plus ¹ module.
Note: High voltage can be present on this connector.
3.2.2.8
The HV cable is used to interconnect high voltage power between the mainframe, Plus¹ and the PSU.
3.2.2.9
This 26 way D-Type connector is situated on the rear of the UI and has three rows of pins. It provides
trigger input and output signals. (see Appendix B).
© The Magstim Company Limited
UI Cable* (1)
Mains Power Switch* (2)
Fuse Access and Voltage Selector* (3)
Power Entry Module* (4)
Link Lead* (5)
Plus¹ Mains Power Switch* (6)
Plus¹ HV Power Output Socket* (7)
HV Cable* (8)
Isolated Trigger Port* (9)
