Tadiran Telecom T200M Series User Manual page 55

station's keyset display. See
[MsgW]
Message Waiting. The Attendant can use this feature to leave a message waiting indication at a busy or idle
station, room or group. See
[Camp]
Camp On, also known as Call Back. Use this feature to have the system automatically call you back when
the busy destination station is available. See
[BrkI]
Break-In enables an authorized user to break into an established two party call. Both conversing parties will
hear the Break In warning tone. Your voice will be heard after the warning tone stops. During Break-In you
can release the ports or alternate between parties. See
NOTE! Only stations with appropriate COS may activate the Break-In feature.
[2Rng]
Send Call Waiting is used to send a call waiting tone to the busy party. This feature is also known as Call
Waiting or Call Offer. The station is now aware that another call is waiting. Your side hears a second
(quicker) ringback tone (system-wide defined).
[VPg]
Voice Page the called party's keyset station using this feature. The other party receives a message that they
are being paged. Your voice is heard over the called party's speakerphone after the warbling tone stops. See
Paging: Voice Paging on page 169
[Num]
Number is used to briefly display the caller's dial number instead of the name.
[Mute]
or MUTE Mute can be activated during busy tone so that if you break-in, your side of the conversation is muted for
silent monitoring (handset, headset and speakerphone). When this feature is activated by the
MUTE
mute feature deactivates the microphone for your speakerphone and handset or headset. Press the toggle key
again to reactivate the microphone. See
[SM2]
2-Way Silent Monitoring is used to monitor both sides of a 2-way conversation simultaneously. This feature
can be activated from idle, or while attempting to call a busy or non-answering destination. At the prompt,
Operating the Phone
Making Internal Calls
Messages: Options on page 149
Leaving a message indication at an idle station: on page 150
.
on/off toggle switch, a bullet appears to the left of
.
Calls Waiting: Receiving on page 89
During a Break In on page 45
[Mute]
Mute Microphone on page
41 T200M Series User Guide (Coral IPx / FlexiCom)
.
.
.
[Mute]
and MUTE LED is lit red. The
163.
or
