T207M/NP, T208M/BL
T207M and T208M
IP Station
Terminal Equipment
Installation, Administration
and Hardware Reference
.
Manual
(Edition 3.1)
Creating a new world of IPportunities

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T208M/BL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tadiran Telecom T208M/BL

Summary of Contents for Tadiran Telecom T208M/BL

  • Page 1 T207M/NP, T208M/BL T207M and T208M IP Station Terminal Equipment Installation, Administration and Hardware Reference Manual (Edition 3.1) Creating a new world of IPportunities...
  • Page 3 The information contained in this document is proprietary and is subject to all relevant copyright, patent and other laws protecting intellectual property, as well as any specific agreement protecting TADIRAN TELECOM (TTL) L.P.'s (herein referred to as the “Manufacturer”) rights in the aforesaid information. Neither this document nor the information contained herein may be published, reproduced or disclosed to third parties, in whole or in part, without the express, prior, written permission of the Manufacturer.
  • Page 4 Record of Changes Edition Issue Date Brief Description • T208M/BL new style (fixed keys with icons, no more labels) May-1-2014 Added PUGW-2G • Dele chapter describes how to convert the phone from SIP to MGCP or from MGCP to SIP...

  • Page 5: Table Of Contents

    Table of Contents About this Manual ................... 1 Document Description ................1 Related Documentation ................3 Special Symbols Used in this Manual ............4 About these Products ..................5 General Information.................. 5 T207/T208 Phone Models ..............10 Installing the Phone..................11 Overview ....................
  • Page 6 Overview ....................35 Preparing for Installation ................ 36 Installing the TEM................... 37 Removing the TEM................. 38 Supplying Power to the Phone ..............39 Overview ....................39 Power over Ethernet “IEEE 802.3AF” - Type A & B ....... 39 Local Power Adapter Option - Type C............ 43 Tips - Defining which Type is Optimal ............
  • Page 7 Configuring the Phone Parameters ............69 Upgrading the Firmware Software............71 Configuring the MGCP Parameters............73 Customizing the Phone ................. 75 Overview ....................75 Printing DESI Labels ................75 Phone Features ..................79 Diagnostics and Troubleshooting ..............81 Overview ....................81 Diagnostics and Troubleshooting ............
  • Page 8 T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 9: About This Manual

     Document Description ........................ The T200M includes the T207M/NP, T208M/BL, T207M and T208MT207S/NP, T208S/BL, T207S and T208S. The T200M Installation Manual is designed for field use by personnel who install these telephones in AeonixCoral FlexiCom and IPx systems. This manual offers detailed information about these telephones, including specifications, internal hardware, interface circuit operation, and installation procedures.
  • Page 10 Description Chapter 9 Configuring the To learn how to configure the T207M/NP, Phone via its Web T208M/BL, T207M and T208M via its web page Page Chapter 10 Customizing the To learn how to print the DESI labels and insert Phone...

  • Page 11: Related Documentation

    Coral IPx/FlexiCom Configuration Program Interface & Database Reference Manual, Version 15.5 or higher T207M/NP, How to use T207M/NP, T208M/BL, T207M and T208M User Guide T208M/BL, T207M for Coral IPx/FlexiCom and T208M T207M/NP, T208M/BL, T207M and T208M Quick User Guide (future)

  • Page 12: Special Symbols Used In This Manual

     Special Symbols Used in this Manual ........................ There is a risk of danger to life or personal injury. There is a risk of damage to equipment. Indicates important information demanding special attention. Tip: Advice that makes it easier to follow the steps of a procedure. NOTES: A page that is intentionally left blank, and can be used for note-taking.

  • Page 13: About These Products

     General Information ........................ The T207M/NP, T208M/BL, T207M and T208M phones are IP telephones that support Media Gateway Control Protocol (MGCP). The T207M/NP, T208M/BL, T207M and T208M combine the ability to communicate with the IP world with the solid dependability and high level of functionality available from the Coral system.
  • Page 14 Ethernet as per IEEE 802.3 AF  Supports multiple Audio Codecs: G.711 a-law/-law, G.729A, G.723.1T207  T208M, T208M/BL - includes a six-line display, 21 characters each line (128x64 pixels)  T207M, T207M/NP - includes a three-line display, 21 characters each line (128x32 pixels) ...
  • Page 15 TEM expansion module (key pad) 2x 22 user programmable keys with removable faceplate Microphone Volume 9 Fixed button function keys Figure 2 T208M/BL Flashing ring 4 Soft keys Phone with Six-line and message waiting indicator Display Graphic display 6 lines Speaker...
  • Page 16 Table 1 T207/T208 Component Description Phone Features Dial Pad (Key Pad) Buttons used to dial a phone number or activate a feature Volume Control Used to adjust the ring, speakerphone, headset, and handset volume During Idle or Ringing: Ring Volume is adjusted During Conversation: speaker,handset or headset volume is adjusted.
  • Page 17 Component Description The Telephone Expansion Module (TEM) is an optional unit that increases the number programmable buttons available on your phone. These 2 x 22 programmable buttons can be configured from the phone or from the phone’s web page. Use the shift left/right buttons to program another 22 buttons.

  • Page 18: T207/T208 Phone Models

    — (128x32)      T208M MGCP 6 lines — (128x64)       T208M/BL MGCP 6 lines (128x64)    T208S 6 lines — — — (128x64)     T208S/BL 6 lines —...

  • Page 19: Installing The Phone

    ........................ This chapter describes the process of installing and configuring T207M/NP, T208M/BL, T207M and T208M phones. It includes all of the procedures from unpacking up to the point that it is ready for use, including: Unpacking the Phone, page 12 ...

  • Page 20: Unpacking The Phone

    Source switch to “Adapter”. Turn the Power Source switch to “PoE”, if Setting the Power over Ethernet (PoE) Switch powered from the LAN. See (T207M, T208M, T208M/BL), page Connecting the Phone to the LAN/PC, Connect the PC port to your PC. See...

  • Page 21: Powering The Phone

     Powering the Phone ........................ An AC power adapter supplying 5VDC / 2A maximum is required for all NP phones. It is not supplied with the phone and must be ordered from the manufacturer, only. The use of any other power adapter will void the warranty. Do one of the following: Connecting the AC ...

  • Page 22: Registering The Phone Via The Coral Ipx / Flexicom

     Coral Version 15.5 or higher  One of the following:  UGW Version 3 or higher for T207M/NP, T208M/BL, T207M and T208M phones, only  PUGW-2G for T207M/NP, T208M/BL, T207M and T208M phones  PUGW Version 7 or higher for T207M/NP, T208M/BL, T207M and T208M phones ...
  • Page 23 Registering the T207M/NP, T208M/BL, T207M and T208M Phones Configure the following T207M/NP, T208M/BL, T207M and T208M phone IP-Ports: Phones (Route: IP,1,0), parameters in the Program Interface. See page Required Zone If the phone is to be defined within a zone, define it to be within the ...

  • Page 24: Registering The Parameters In The Phone

    Registering the Parameters in the Phone ........................ The phone parameters can be configured locally, from the phone or from its web page.  To configure the T207M/NP, T208M/BL, T207M and T208M parameters Configuring the Phone via its Dial Pad, page from the phone, see ...
  • Page 25 Configure the Call Agent address  For phones connected to the same server that houses the UGW card, configure the Call Agent address to the local IP address of the UGW card.  For phones connected to a UGW card positioned behind the NAT, configure the Call Agent address to the global IP address of the UGW card.

  • Page 26: Completing The Registration And Customizing Your Phone

     Completing the Registration and Customizing your Phone ........................ Customizing the Phone, page Customize the phone user settings. See Record the phone’s details on the form provided in Table 4. These parameters might be necessary for future configuration. Installing the Phone T200M Series Installation Manual - Coral IPx / FlexiCom...
  • Page 27 Table 4 Station Number information form for T207/T208 Phones Numbering Plan MAC # Port List IP Address Station Location Route: NPL,0 [41] Route: IP, 1 Route: PLIS,1 Index # Dial Number Record the phone Short Full Name: (max: Enter the physical IP address when a Name 16 char.)
  • Page 28 Installing the Phone T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 29: Phone Hardware Description

    Phone Hardware Description  Overview ........................ This chapter describes in detail the hardware features of the phones and provides a detailed description of how to unpack and install the phones.  Unpacking and Assembling the Phone ........................ Inspect for Damage Inspect the shipping carton for evidence of damage or mishandling prior to opening.
  • Page 30 The following items are not shipped with the phone:  AC Wall Power adapter with 115/230VAC 60/50Hz input and 5VDC output at 2A. (It is not supplied with the phone and must be ordered from the manufacturer, only.) Figure 4 T20x Package wall-mounting template MESSAGE...
  • Page 31  The FCC symbol indicates that the phone adheres to the standards of the FCC. This symbol also appears on the bottom panel of the phone.  The wheelie-bin symbol indicates that the phone must be discarded according to local regulations. This symbol also appears on the bottom panel of the phone.
  • Page 32 Installing the Handset The handset cord comes with the same connector type on both ends. Take one end of the cord and place it into the socket located at the bottom of the handset. The connector fits properly in one direction only. If the connector does not fit into the socket easily, turn it over and retry.

  • Page 33: Connecting To The Network (Lan / Pc)

    Connecting to the Network (LAN / PC) ........................ Setting the Power over Ethernet (PoE) Switch ( T207M, T208M, T208M/BL Before connecting the cables, verify that the Power over Ethernet (PoE) switch is switched to the correct setting, if applicable (in some models).
  • Page 34 Figure 9 T207/T208 Connection to LAN/PC power adapter 5VDC...2A DC-IN The ONLY AC power adapter that can be used with the phone is one purchased from the manufacturer. *The use of any other AC power adapter will void the warranty* Table 5 LAN Interface Pin #...
  • Page 35 Table 6 PC Interface Pin # Connections Pin 1 Pin 2 Pin 3 Pin 4 not used Pin 5 not used Pin 6 Pin 7 not used Pin 8 not used Figure 10 LAN/PC Interface Connector PIN Assignment RJ-45 T200M Series Installation Manual - Coral IPx / FlexiCom Phone Hardware Description...
  • Page 36 Daisy Chaining You can also ‘daisy chain’ additional T207 / T208 phones by connecting the LAN connector of the additional phones to the PC connector of the original phone. Using this technique, many phones may be operated from the same LAN socket. The daisy chain layout is ideally suited to situations in which all phones are installed on the same desk.
  • Page 37 Connecting the Phone to the LAN/PC To connect the phone to the local LAN: Fabricate a cable for connection to the LAN as described in Table 5. Ensure that the length of the straight-through cable between the switch and the station does not exceed 100 meters, including all patch cables and cross connect wires.
  • Page 38 Line Distances The T207/T208 is designed to operate over Ethernet LAN with a connection of up to 100 meters to the local switch when using Category 5 UTP (unshielded twisted pair). Figure 13 below for an illustration of the placement of IP stations in relation to their LAN hubs.

  • Page 39: Positioning And Mounting The Phone

     Positioning and Mounting the Phone ........................ The phone can be mounted on a wall or on a desk. The desk mounting procedure is Mounting the Phone onto described below. The wall-mounting procedure is described on the Wall, page Positioning the Phone on your Desk The desk-mounting bracket is used to elevate the rear of the phone on a desktop in order to lower the viewing angle of the phone display.
  • Page 40 Mounting the Phone onto the Wall Using a flat blade screwdriver, pry latches A and B on both sides of the desk-mounting bracket. Remove latches from the desk-mounting bracket, and remove the bracket from the phone. Reinsert the latches into the desk-mounting bracket. Figure 15 Preparing the Phone for Mounting onto the Wall...
  • Page 41 Figure 16 Wall-Mounting Template This way up This way up Make a mark on the wall in each of the template holes as indicated in Figure Use a small drill bit (#7, 13/64”, 5mm or smaller) to drill three holes into the wall for the mounting screws.
  • Page 42 Figure 17 Mounting the Phone onto the Wall Fold the U-type frame onto the back of the phone. Connect cables to A and B Line up C, D and E with Reset Source Adapter screws on the wall and mount the phone Press down cradle latch...

  • Page 43: Tem Expansion Unit Description

    TEM Expansion Unit Description  Overview ........................ The TEM (Telephone Expansion Module) is a digital programmable expansion module that can be added onto the T200M Series telephone set. It increases the number of programmable buttons available on the phone. The TEM is powered by the telephone set.

  • Page 44: Preparing For Installation

     Preparing for Installation ........................ Inspect for Damage Inspect the shipping carton for evidence of physical damage or mishandling prior to opening. Inspect all parts for damage. Report any damage to the carrier immediately. If it is necessary to make a damage claim to the carrier, do not move the shipping carton until it has been examined by a representative of the carrier.

  • Page 45: Installing The Tem

     Installing the TEM ........................ Remove the power and the LAN cords from the phone, if connected. Remove the protective rubber cover from the two sleeves on the right side of the phone. Insert the shafts on the TEM into the sleeves affixed to the right side of the phone.

  • Page 46: Removing The Tem

     Removing the TEM ........................ Remove the power and the LAN cords from the phone, if connected. Unfasten the screws from the mating holes of the TEM unit-phone assembly. Figure Extract the TEM unit from the phone. See Figure TEM Expansion Unit Description T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 47: Supplying Power To The Phone

    ........................ The phone requires external power at all times. There are three options to power the phone.  Type A (for T207M, T208M, T208M/BL) provides Power over the Ethernet (PoE) according to the IEEE 802.3AF standard. See Figure  Type B (for T207M, T208M, T208M/BL) provides Power over the Ethernet (PoE) according to the IEEE 802.3AF standard.
  • Page 48 Verify that there are no split cables within the facility. Additional cabling work might be required. See Figure Figure 21 Power over Ethernet LAN (Type A) for T207M, T208M and T208M/BL PHY-1 INTERFACE CIRCUITRY POWER SWITCHING -48VDC &...
  • Page 49 If the phone includes a PoE/Adapter switch on the rear of the phone base, it must be set to “PoE”, (see Figure 8 on page 25). T200M Series Installation Manual - Coral IPx / FlexiCom Supplying Power to the Phone...
  • Page 50 100MB LANs. Therefore, shortcomings in cabling should not be an issue. See Figure Figure 22 Power over Ethernet LAN (Type B) for T207M, T208M and POWER SWITCH & T208M/BL CURRENT LIMIT -48VDC Comply with the IEEE 802.3af Standard PHY-1...

  • Page 51: Local Power Adapter Option - Type C

     Local Power Adapter Option - Type C ........................ All phone types can be powered directly from the AC power supply. Power is supplied from a local power adapter plugged into the AC (115V or 230V) power wall receptacle via the DC power jack on the rear panel. See Figure 23 Figure 8 on page Figure 23 AC Power...
  • Page 52 Single Unit Power Supply The manufacturer supplies an external, single unit, AC wall power adapter. With an input of 115VAC 60Hz or 230VAC 50Hz and an output of 5VDC 2A maximum output:  115VAC 60Hz input, 5VDC 2A max.output - CN.77440952800 (US pin) ...

  • Page 53: Tips - Defining Which Type Is Optimal

     Tips - Defining which Type is Optimal ........................ The phone requires external power at all times. An AC wall power adapter (type C) for powering the phone is the most obvious and immediate means; it is both the easiest from an installation standpoint and currently the most cost-effective approach to providing power to the phone.

  • Page 54: Connecting To Poe (Type A And B)

     Connecting to PoE (Type A and B) ........................ If a PoE/Adapter switch is available on the bottom of the phone, turn it to “PoE”. See Figure 8 on page  Connecting the AC Wall Power Adapter (Type C) ........................ The manufacturer supplies an external, single unit AC power supply adapter.

  • Page 55: Checking The Phone Connectivity

     Checking the Phone Connectivity ........................ At this point, the phone can be tested for connectivity with a ping test. It is not necessary to configure the PI or the phone before testing connectivity. The factory-defined static IP address of the phone is 192.168.1.10. If your workstation is configured to an assigned static IP address, record the IP address on a piece of paper.
  • Page 56 Supplying Power to the Phone T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 57: Coral Ipx And Flexicom Registration

    FlexiCom 400, 5000, 6000) for T207M/NP, T208M/BL, T207M and T208M phones  CUGW Version 7 or higher (Coral IPx Office) for T207M/NP, T208M/BL, T207M and T208M phones The following Coral PI database parameters must be defined prior to connecting the phone to the LAN.

  • Page 58: Parameters For Reference

     Necessary IP addresses that are used to define the IP address of the Call Agent of the T207M/NP, T208M/BL, T207M and T208M phone. This chapter does not include general IP parameters that must be configured within the Coral system in order for it to enable basic IP functionality. For an outline of general IP parameters, refer to the VoIP Installation Manual.

  • Page 59: General Parameters

    IP_MEDIA_CHANNELS - Defines the maximum number of IP media channels  supported by the Coral. Set these parameters to accommodate the total number of IP terminals and channels expected to be used. Verify that the maximum number of IP terminals and channels are defined.

  • Page 60: Phone Registration Parameters

    T208M/BL, T207M and T208M phones is automatically recorded by the system. The MAC address of the T207M/NP, T208M/BL, T207M and T208M phone can be Configuring found on the rear panel or by retrieving it from the phone as described in the Phone Networking Parameters, page 57.

  • Page 61: Post-Registration Test Parameters

    After completing registration, the registration status of the T207M/NP, T208M/BL, T207M and T208M phones can be checked: IP-Ports: Phones ............(Route: IP,1,0) STATUS - provides the registration status of T207M/NP, T208M/BL, T207M and T208M phones. ACTIVE - Successful registration. T200M Series Installation Manual - Coral IPx / FlexiCom...
  • Page 62 Coral IPx and FlexiCom Registration T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 63: Configuring The Phone Via Its Dial Pad

    Configuring the Phone via its Dial Pad  Overview ........................ Before configuring the T207M/NP, T208M/BL, T207M and T208M, verify that all of the necessary parameters have been configured via the Coral FlexiCom or IPx. See Checking the Phone Connectivity, page Figure 25 T207M and...
  • Page 64 This section describes the T207M/NP, T208M/BL, T207M and T208M configuration via the phone: Configuring the Phone Networking Parameters, page 57  Configuring the Operating Mode, page 58  Viewing the Diagnostics, page 59  Configuring the Phone via its Dial Pad...

  • Page 65: Configuring The Phone Networking Parameters

     Configuring the Phone Networking Parameters ........................ Click the OK fixed key for at least three seconds on the phone. [Sysdef] Select and enter the password (default = 159753) at the prompt. Select IP Parameters. [Edit] Click and modify the IP parameter to be configured. For a list of parameters, see Table [Esc]...

  • Page 66: Configuring The Operating Mode

     Configuring the Operating Mode ........................ Press the OK fixed key for at least three seconds on the phone. [SysDef] Select and enter the password (default = 159753) at the prompt. Select Operating Mode. Select the Operating Mode. See Table [Esc] Press several times until the following prompt is displayed:...

  • Page 67: Viewing The Diagnostics

     Viewing the Diagnostics ........................ Click the OK fixed key for at least three seconds on the phone. [SysDef] Select and enter the password (default = 159753) at the prompt. Scroll to the relevant Diagnostics parameter. See Table [Esc] Click several times until the following prompt is displayed: Restart the phone to apply the new settings? 000.000.000.000...
  • Page 68 Configuring the Phone via its Dial Pad T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 69: Configuring The Phone Via Its Web Page

    IP address. It is recommended that T207M/NP, T208M/BL, T207M and T208M telecommuters use dynamic addresses. If a parameter is defined as dynamic, the T207M/NP, T208M/BL, T207M and T208M will attempt to contact a DHCP and/or DNS Server to retrieve the information for that parameter.

  • Page 70: Browsing To The Phone Web Page

     Browsing to the Phone Web Page ........................ To browse to the Phone Settings Web Page: The factory-defined static IP address of the phone is 192.168.1.10. To reach the Web page of the phone, do one of the following:  Temporarily assign a static IP address to your workstation that is on the same IP network as the factory defined IP address of the phone.
  • Page 71 Users have access to all configuration option tabs except the MGCP tab where the Call Agent settings are defined. Click OK . The Web page of the T207M/NP, T208M/BL, T207M and T208M is displayed with the Information tab. The Information tab displays the phone settings. This page displays the different details currently configured for the phone.
  • Page 72 Table 10 Information Parameter Description Phone IP Type Displays the IP type: static or dynamic Current IP Displays the current IP address (dynamic or static, whichever is relevant as per IP Type above) Subnet Mask Displays the subnet mask (0.0.0.0) for dynamic Default Displays the default gateway...

  • Page 73: Configuring The Phone Network Parameters

     Configuring the Phone Network Parameters ........................ Figure 29 Table 11 list all of the T207M/NP, T208M/BL, T207M and T208M phone Network parameters, their meanings, and the corresponding parameters in the phone. Figure 29 Network Parameters T200M Series Installation Manual - Coral IPx / FlexiCom...
  • Page 74 Table 11 Network Parameter Description Phone Parameters Private Key Server directory and filename of private key used to encrypt authentication request. The private key is uploaded along with either the personal, root, or trusted certificate. 1. Click Browse and select the directory and filename of the private key.
  • Page 75 Parameter Description Phone IP Type Select Static or DHCP to define the SysDef > IP Parameters > mode of IP address definition for the Network Type > Static phone. IP/DHCP This field is automatically updated from the phone. IP Address Use this field to enter a Static IP SysDef >...
  • Page 76 Parameter Description Phone 802.1x Type Defines the specific protocol used for 802.1x auscultation: Off - 802.1 authentication is not used. EAP-MD5 - Uses MD5 protocol EAP-TLS - Uses TLS protocol 802.1x Items 802.1x Defines the 802.1x authentication Identity username - provided by the system administrator 802.1x Defines the 802.1x authentication...

  • Page 77: Configuring The Phone Parameters

    Configuring the Phone Parameters ........................ Figure 30 Table 12 list all of the T207M/NP, T208M/BL, T207M and T208M phone parameters, their meanings, and the corresponding parameters in the phone. Figure 30 Phone Settings T200M Series Installation Manual - Coral IPx / FlexiCom...
  • Page 78 Table 12 Phone Settings Parameter Description Phone Administrator Defines the Administrator Name name for login Administrator Defines the Administrator Password password for login Account Settings User Name Defines the user name for login User Defines the user password for Password login Handset Mic Sets the volume of the...

  • Page 79: Upgrading The Firmware Software

    ........................ Figure 31 Table 13 list all of the SwUpgrade parameters, their meanings, and the corresponding parameters in the T207M/NP, T208M/BL, T207M and T208M phone. Figure 31 Software Upgrade T200M Series Installation Manual - Coral IPx / FlexiCom Configuring the Phone via its Web Page...
  • Page 80 Table 13 Software Parameter Description Phone Upgrade Select Enter the filename of the Firmware to software to be uploaded and Upgrade: click Upload. Upgrade by Select Profile Enter the filename of the HTTP to Upgrade: profile to be or saved or uploaded and click Upload or Download Settings.

  • Page 81: Configuring The Mgcp Parameters

     Configuring the MGCP Parameters ........................ Figure 32 Table 14 list all of the MGCP parameters, their meanings, and the corresponding parameters in the T207M/NP, T208M/BL, T207M and T208M phone. Figure 32 MGCP Parameters Table 14 MGCP Parameters Parameter Description...
  • Page 82 NOTES:...

  • Page 83: Customizing The Phone

    Customizing the Phone  Overview ........................ Customizing the phone is covered in detail in the T200M Series User Guide. To personalize and program the buttons for the phone, refer to the following sections in the Configuration User Guide:  Using the programmable keys ...
  • Page 84 Table 15 DESI Labels Label Sheet Catalog # Phone Model Details Letter (8 ½ x 11”) T207M, T207M/NP, T208M 7744-7300066 7744-7300067 4 buttons 7744-7300068 7744-7300069 22 buttons Printing the Multi-Designation Label Use the DESI software to select the layout of your multi-designation label (as described on the previous page).
  • Page 85 Figure 34 Inserting DESI Label over the TEM Unit Lift up using a paper clip to remove flexible vinyl overlay T200M Series Installation Manual - Coral IPx / FlexiCom Customizing the Phone...
  • Page 86 NOTES:...

  • Page 87: Phone Features

    Phone Features ........................ Most features of the T207M/NP, T208M/BL, T207M and T208M phones are activated from the Coral database. The features available depend on system constraints and are managed by the system administrator. To activate these features from the Coral database, refer to the Program Interface &...
  • Page 88 Customizing the Phone T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 89: Diagnostics And Troubleshooting

      Diagnostics and Troubleshooting ........................ Table 16 T207M/NP, Symptom Meaning Required Action T208M/BL, T207M and T208M Diagnostics and Your display panel is Your phone. is not powered. Check the power Troubleshooting blank AND the buttons connection to your phone.
  • Page 90  If the message remains, the Define the correct Call Agent address in the IP phone is unable to T207M/NP, T208M/BL, communicate with the. T207M and T208M Define the Call Agent address as dynamic and ensure the phone’s IP...
  • Page 91 Symptom Meaning Required Action The following message Phone is not in the same zone Do one of the following: appears: as the gateway  Remove the phone from WRONG ZONE SETUP its existing zone.  Configure the phone to be in the same zone as the primary UGW.

  • Page 92: Problems During Installation

     Problems During Installation ........................ Problem Solution Phone does not work Check the following:  Ethernet cable is connected  Power Source switch, if present, is properly set (PoE/Adapter)  AC power adapter is connected, if applicable No dial tone Check the following: ...

  • Page 93: Failure Messages During Installation

    Make a note of the MAC address UNREGISTERED MAC registered. that is displayed on the T207M/NP, T208M/BL, T207M and T208M and enter this information. The MAC address can be found written on a label on the bottom of the T207M/NP, T208M/BL, T207M...
  • Page 94 T208M/BL, T207M and it into the Self IP field on the T208M is invalid. T207M/NP, T208M/BL, T207M and T208M: [SysDef] > IP Params > Static > Self IP Adr There is no Subnet Mask...
  • Page 95 Enter the DNS Server IP Address DNS Server Address defined in the phone. into the relevant field on the is missing... T207M/NP, T208M/BL, T207M and T208M: [SysDef] > IP Params > Static > DNS IP Adr Define the DNS IP Address as...

  • Page 96: Failure Messages During A Call

    Sentinel resources are engaged. The Sentinel resources are freed once another user ends a conversation. WRONG ZONE SETUP The T207M/NP, T208M/BL, T207M Configure the zone of the phone as and T208M is attempting to connect to the same zone used by the UGW to...

  • Page 97: Upgrading The Phone Firmware

    Upgrading the Phone Firmware  Overview ........................ The phone firmware is regularly enhanced to provide new features. You can upgrade the phone by downloading its latest version from the manufacturer’s website. This section describes the following: Upgrading the Phone Firmware, page 90 ...

  • Page 98: Upgrading The Phone Firmware

     Upgrading the Phone Firmware ........................ To upgrade the T207M/NP, T208M/BL, T207M and T208M firmware, do the following: Download the latest firmware version from the manufacturer’s web site. Access the manufacturer’s website at http://www.tadirantele.com Go to Partners login, type your username and password.
  • Page 99 On your workstation, open your browser and type the IP address into the address bar and browse to the web page of the MGCP keyset. The login window is displayed. Login to the web page portal. In the SwUpgrade tab of the web page, download the file from the TFTP Upgrading the Firmware Software, page 71).
  • Page 100 After the software has been upgraded, the following message is displayed: WRITING COMPLETE After this message has been displayed, the phone initializes. If these messages are not displayed, a problem was encountered and it might be necessary to perform the Rescue Rescue Update Procedure, page Update procedure.

  • Page 101: Rescue Update Procedure

     Rescue Update Procedure ........................ If the phone software has been corrupted, the phone can be updated with a manufacturer-supplied version using the following procedure: To perform the Rescue Update procedure: Disconnect the power from the phone and reconnect it while clicking the first softkey on the left;...
  • Page 102 Upgrading the Phone Firmware T200M Series Installation Manual - Coral IPx / FlexiCom...

  • Page 103: Specifications

    Material: ABS plastic Programmable Buttons: Alphanumeric Display: T207M, T207M/NP: 128 x 32 pixels (3 lines, 21 characters each) T208M, T208M/BL: 128 x 64 pixels (6 lines, 21 characters each) Back Light: T208M/BL Power over Ethernet “PoE” T207M, T208M, T208M/BL AC Power Adapter T207M, T208M, T208M/BL, T207M/NP ...
  • Page 104 (see Type-A/B ..........5.0W Max. Power over Ethernet (PoE) (IEEE-802.3af Standard) Type-C ..........AC Wall Power Adapter (see below) Power Source Option: T207M, T208M, T208M/BL....PoE, Adapter T207M/NP........... Adapter only AC Wall Power Adapter: Not Supplied With Phone Input: 110-240VAC, 50/60Hz Output: 2000mA Max.
  • Page 105 Optional Accessories: TEM Expansion Module Encoding standards: Supports all SIP codecs IP Protocol: MGCP Features: All Coral features Coral Software Version: 15.5 or higher Phone Version: 9 or higher Voice Handling: Supports multiple Audio Codecs: G.711 a-law/ u-law, G.729A, G.723.1 (6.3K/5.3K). Supports VAD (Voice Auto Detection) and CNG (Comfort Noise Generation).
  • Page 106 NOTES: Specifications T200M Series Installation Manual - Coral IPx / FlexiCom...
