Printing the multi-designation label:
• Use the DESI software to select the layout of your multi-designation label (as described on the previous page)
• Enter the button content names per button location
• Load the label sheet into the printer tray
• From the DESI Plus/DESI Lite menu, choose File > Print
To place labels:
1. Create and print the labels using the DESI software.
2. Remove the vinyl overlay with a paper clip, refer to figure below.
3. Affix your new button label/s.
4. Replace the vinyl overlay.
Button labelling for T207M & T207M/NP with TEM
Station Telephony Features
Programming: Button Labeling
Lift up using
a paperclip to
remove flexible
vinyl overlay
Button labelling for T208M
186 T200M Series User Guide (Coral IPx / FlexiCom)
Lift up using
a paperclip to
remove flexible
vinyl overlay
