AD9739
Pin No.
L1, M1
L2, M2
L3, M3
L4, M4
L5, M5
L6, M6
L7, M7
L8, M8
L9, M9
L10, M10
L11, M11
L12, M12
L13, M13
L14, M14
N1, P1
N2, P2
N3, P3
N4, P4
N5, P5
N6, P6
N7, P7
N8, P8
N9, P9
N10, P10
N11, P11
N12, P12
N13, P13
N14, P14
1
Conforms to IEEE-1596 reduced range link.
Mnemonic
DB1[0]P/DB1[0]N
DB1[1]P/DB1[1]N
DB1[2]P/DB1[2]N
DB1[3]P/DB1[3]N
DB1[4]P/DB1[4]N
DB1[5]P/DB1[5]N
DB1[6]P/DB1[6]N
DB1[7]P/DB1[7]N
DB1[8]P/DB1[8]N
DB1[9]P/DB1[9]N
DB1[10]P/DB1[10]N
DB1[11]P/DB1[11]N
DB1[12]P/DB1[12]N
DB1[13]P/DB1[13]N
DB0[0]P/DB0[0]N
DB0[1]P/DB0[1]N
DB0[2]P/DB0[2]N
DB0[3]P/DB0[3]N
DB0[4]P/DB0[4]N
DB0[5]P/DB0[5]N
DB0[6]P/DB0[6]N
DB0[7]P/DB0[7]N
DB0[8]P/DB0[8]N
DB0[9]P/DB0[9]N
DB0[10]P/DB0[10]N
DB0[11]P/DB0[11]N
DB0[12]P/DB0[12]N
DB0[13]P/DB0[13]N
Rev. A | Page 10 of 56
Description
Port 1 Positive/Negative Data Input Bit 0.
Port 1 Positive/Negative Data Input Bit 1.
Port 1 Positive/Negative Data Input Bit 2.
Port 1 Positive/Negative Data Input Bit 3.
Port 1 Positive/Negative Data Input Bit 4.
Port 1 Positive/Negative Data Input Bit 5.
Port 1 Positive/Negative Data Input Bit 6.
Port 1 Positive/Negative Data Input Bit 7.
Port 1 Positive/Negative Data Input Bit 8.
Port 1 Positive/Negative Data Input Bit 9.
Port 1 Positive/Negative Data Input Bit 10.
Port 1 Positive/Negative Data Input Bit 11.
Port 1 Positive/Negative Data Input Bit 12.
Port 1 Positive/Negative Data Input Bit 13.
Port 0 Positive/Negative Data Input Bit 0.
Port 0 Positive/Negative Data Input Bit 1.
Port 0 Positive/Negative Data Input Bit 2.
Port 0 Positive/Negative Data Input Bit 3.
Port 0 Positive/Negative Data Input Bit 4.
Port 0 Positive/Negative Data Input Bit 5.
Port 0 Positive/Negative Data Input Bit 6.
Port 0 Positive/Negative Data Input Bit 7.
Port 0 Positive/Negative Data Input Bit 8.
Port 0 Positive/Negative Data Input Bit 9.
Port 0 Positive/Negative Data Input Bit 10.
Port 0 Positive/Negative Data Input Bit 11.
Port 0 Positive/Negative Data Input Bit 12.
Port 0 Positive/Negative Data Input Bit 13.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
