6.1.6 Configuring the BMC Network
To view the current configuration of BMC IPv4 or BMC IPv6 network:
1. Login to the BIOS Setup Menu.
2. Select "Server Mgmt → BMC Network Configuration BMC → IPv4 Network
Configuration/BMC IPv6 Network Configuration".
Parameter
Get BMC Sharelink
Parameters / Get BMC
Dedicated Parameters
Configuration Address
Source
Station IP address
Subnet mask
Station MAC address
Router IP address
BIOS Settings
Table 6-5
BMC Network Configuration
Description
Set a method to get the BMC Sharelink /
Dedicated Management Channel
Options:
•
Do Nothing
•
Auto: Automatically get the current BMC
network Settings
•
Manual: Manually set the BMC network
Display the current BMC network parameters
NOTE: This item is only available when
Get BMC Dedicated Parameters is set to
[Manual].
Options:
•
Unspecified: Unspecified option will not
modify any BMC network parameters
during BIOS phase.
•
Static: Statically obtain BMC network
information
•
DynamicBmcDhcp: Dynamically obtain
BMC network information
NOTE: Static and dynamic network
parameter Settings take effect immediately.
Display IP Address information
Display Subnet Mask information
NOTE: The IP address must be in Hex
format, for example, 6c-92-bf-a2-b8-c6.
Display the MAC Address information
Display the Router IP Address information
Default Setting /
Format
Do Nothing
Unspecified
0.0.0.0
xx-xx-xx-xx-xx-xx
0.0.0.0
0.0.0.0
33
