Chapter 6 — Retrieving and Printing a Form

Example

32
The form "TEST" edited in the previous chapter can be retrieved
and printed from any ASCII-sending device using this sequence:
Command Explanation
CR/LF to start command structure
Retrieve form
FR"TEST"
Call for variables
?
Substitute variable V00
EASYCODER
Substitute variable V01
501SA
Substitute variable V02
Dan
Counter start value C0
100000
Print 2 copies of a single label
P1,2
Note: It is critical to the syntax to send exactly the same number
of variable lines as defined for the label form.
The question mark (?) following the FR command is required for
printing any fields edited in Form Edit mode that contain
variables or counters. If no question mark is transmitted, all fields
containing variable input are omitted from the printout.
Variables and counter start values must be defined, either by
programming or by user input.
