Chapter 1 — Introducing ESim

Field

8
Most computer-based systems send CR/LF when pressing the
Enter key. The CR (carriage return) sent in a CR/LF sequence is
ignored. Sending a CR alone has no effect.
Refer to Chapter 2,
information on when the various commands can be used.
ESim commands and parameters must be used only as
described in this manual. Use of unknown commands and
parameters may cause permanent printer malfunction.
Each command line of printable data creates a field with certain
values for start position, rotation, magnification, and so forth.
SAM BY:
Variable
text V00
Graphic
The illustration shows how a label is printed and fed out using the default
direction.
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
"Command List" on page 11
Box
PACKED
76532
NAME PRODUCT
654 NO.
Feed
direction
for
Counter C1
Rotated text
Rotated text
Line
Fixed text
Counter C0
SERIAL
Y axis
X axis
