Remarks:

Z - Print Direction

Purpose:
Syntax:
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
Y Command Parameter Descriptions (continued)
Parameter Description
p Number of data bits:
3
7 = 7 data bits
8 = 8 data bits
p Number of stop bits:
4
1 = 1 stop bit
2 = 2 stop bits
After receiving this command, the printer automatically resets its
communication on the serial RS-232 communication port.
There are no such parameters for the USB port.
By default, the printer is set for 9600 baud, no parity, 8 data bits,
1 stop bit. XON/XOFF handshaking is always used. The printer
sends XOFF when an error occurs. RTS/CTS is not supported.
If the current communication setup is not known, it can be
checked by printing a test label, see
page 3 for more information on how to print a test label.
Example:
In this example, we are setting a 19,200 baud rate, odd parity, 7
data bits, and 1 stop bit.
Y19,O,7,1
This command is used to select the print orientation
Zp
1
.
Z Command Parameter Descriptions
Parameter Description
p Print orientation:
1
T = Start printing from the top of image buffer
(default).
B = Start printing from the bottom of image
buffer.
Chapter 7 — Commands
"Autosensing Mode" on
