Intermec EasyCoder PC4 Programmer's Reference Manual page 79

Chapter 7 — Commands
Recommended Density Settings For Direct Thermal Printing
Label/Tag Type
Duratherm II
Duratherm II Tag
Duratherm Lightning
Duratherm IR
Thermal Top
Thermal Eco
Thermal Top Board
Thermal Eco Board
Thermal IR
Thermal Top High Speed
Duratherm Lightning
64
• Different ambient temperature and humidity.
The printed information may also require the density to be
adjusted. Typically, this applies to different bar code orientations
and densities. Refer to the tables in the pages that follow for
recommended initial settings.
Test after the print speed has been set, see
page 107, and make further adjustments until you have found
the settings which best apply to your unique application.
Example:
To select a printhead density of 9, enter the command below:
D9
Recommended density settings are identified in the following
tables. Further adjustments might be necessary depending on
print speed, bar code density, orientation, and ambient
temperature/humidity conditions.
Recommended
Density at Speed
S = 2
D10
D9
D9
D7
D8
D8
D11
D7
D12
D6
D9
ESim for the PC4 and PF8 Printer Programmer's Reference Manual
"S - Speed Select" on
Maximum Speed
S3
S1
S3
S3
S3
S3
S2
S2
S3
S3
S3
